Custom Industrial Machinery Tools

Our custom custom industrial machinery tools are for a wide range of customers in heavy equipment, agriculture, mining, appliance, aircraft-aerospace and automotive industries. We work with our customer, as a team, to develop a workable concept and then follow the custom industrial machinery tools project to a 100% completed engineered design.  Our Engineering department specializes in designing large to small custom industrial machinery tools, holding fixtures and many other specialty tools / gages with optional manual, hydraulic or pneumatic clamping. Fixtures can be integrated with robotics when necessary.

1. Materials that are available for tooling machining fixtures
 Fe: Fe360/ 1045/ 1049/ P20/ S136/ M2/ H13/ D2/ 440C/ 4140/ O1
Stainless Steel: 303/ 304/ 316
Al: 2017/ 5052/ 6061/ 7075
Cu: C11000/ C27400 /C34200/ C17200
Resin: Plastic/ Nylon/ POM/ Teflon/ Resin/ POM/ ABS
Else: Bakelite/ Organic glass/ Ti/ Mo / Derlin/ Peek/ Ceramics

2. Metal processing available for tooling machining fixtures

3. Surface Finish available

Laser-printing, clear/ black anodizing, zinc plating, chrome plating, electroplating and nitriding are common treatments in SGI factory.

4. Tolerance for the cnc machining machining fixtures
 From simplest to precision of +/- 0.005mm.

5. Files formats accepted when clients send us drawing

 3D: Pro/E . UG . MasterCam
 2D: AutoCad
 Accepted file format: .igs .prt .stp .x_t .dxf .dwg .pdf .jpg .tif .jpg .bmp .doc .xls.

6. SGI service team

7. Delivery

DHL, FedEx, UPS for small kilos( 2- 3 days); By sea for big kilos( 30 days).
