Led 12v power supply 24W ac/dc adapter switching power adapter 12V 2A
Key Specifications/Special Features:
Output
DC Voltage............12V DC ±3
Rated Current............2A
Raded Power............24W
Ripplt & noise(Max)............ mVp-p is less than or equal to 1% Uout
Load Regulation .............. ±1%
Input
Voltage range............... 100~240 V AC 47~63 Hz
Efficiency ..............> 75%
AC Current (Max) .................. 0.15A/220V 0.25A/115V
AC Inrush Current................ 30A/230V
Protection Function
Short Circuit protection
Over load ............130%~150%
Over Voltage ............115%~135%
Environment
Working temP.............. 0~50°C
Working humidity............. 20%~90% RH
Storage temp humidity............ 20%~95%RH
Safety Approvals: CE, FCC, ROHS...
Protections
1)over voltage protection: 120%min
2)over current protection: 120%min
3)over load protection hiccp mode,auto-recovery
4)Short-circuit protection: automatic recovery
5)Load regulation: ±5%
Environmental requirement
1)operating temperature: 0-40
2)storage temperature: -20-85
3)opera ting relative humidity:595%RH
4) Withstanding voltage: AC 3,000V (minimum), 5mA (maximum)
5)Insulation resistance: DC 500V 100MΩ (minimum)
Packing details:1 piece per plastic bag/Bubble bag+inner box+power plug (negotiate when order)
FIT FOR ANY DIGITAL PRODUCTS LIKE LCD & LED SCREEN,SCANNER,MEDICAL EQUIPMENT,PRINTER,DIGITAL FRAMES,PBX,ADSLMODEL.....
Our Adavantages:
1) Over 8 years of professional experience in design and producing ac adpters.
2) Strong R&D Capability, all kinds of products available:ac/dc adapters,Laptop adapters,Universal laptop chargers,Laptop car charger,tablet pc charger and Irregular power adapters
3) Abundant inventory for fast delivery.
4) Reliable quality
5)Warranty 2year:we change your no working adapter 1 to 1
6)Brand New Replacement Product, works as genuine parts, 100% OEM Compatible!!
Package Includes
-
One Unit AC Power Adapter with bags and box.
-
Bulk packing
-
-
-
-
Key Specifications/Special Features:
Output
DC Voltage............12V DC ±3
Rated Current............2A
Raded Power............24W
Ripplt & noise(Max)............ mVp-p is less than or equal to 1% Uout
Load Regulation .............. ±1%
Input
Voltage range............... 100~240 V AC 47~63 Hz
Efficiency ..............> 75%
AC Current (Max) .................. 0.15A/220V 0.25A/115V
AC Inrush Current................ 30A/230V
Protection Function
Short Circuit protection
Over load ............130%~150%
Over Voltage ............115%~135%
Environment
Working temP.............. 0~50°C
Working humidity............. 20%~90% RH
Storage temp humidity............ 20%~95%RH
Safety Approvals: CE, FCC, ROHS...
Protections
1)over voltage protection: 120%min
2)over current protection: 120%min
3)over load protection hiccp mode,auto-recovery
4)Short-circuit protection: automatic recovery
5)Load regulation: ±5%
Environmental requirement
1)operating temperature: 0-40
2)storage temperature: -20-85
3)opera ting relative humidity:595%RH
4) Withstanding voltage: AC 3,000V (minimum), 5mA (maximum)
5)Insulation resistance: DC 500V 100MΩ (minimum)
Packing details:1 piece per plastic bag/Bubble bag+inner box+power plug (negotiate when order)
FIT FOR ANY DIGITAL PRODUCTS LIKE LCD & LED SCREEN,SCANNER,MEDICAL EQUIPMENT,PRINTER,DIGITAL FRAMES,PBX,ADSLMODEL.....
Our Adavantages:
1) Over 8 years of professional experience in design and producing ac adpters.
2) Strong R&D Capability, all kinds of products available:ac/dc adapters,Laptop adapters,Universal laptop chargers,Laptop car charger,tablet pc charger and Irregular power adapters
3) Abundant inventory for fast delivery.
4) Reliable quality
5)Warranty 2year:we change your no working adapter 1 to 1
6)Brand New Replacement Product, works as genuine parts, 100% OEM Compatible!!
