12V 10A Waterproof Solar Charge Controller
-
USD21.9≥200 Piece/Pieces
- Payment Type:
- T/T, Paypal
- Incoterm:
- FOB
- Min. Order:
- 200 Piece/Pieces
- Min. Order:
- 200 Piece/Pieces
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Land, Air
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen China(Mainland) |
|---|---|
| Productivity: | 50,000pcs/month |
| Supply Ability: | 50,000pcs /month |
| Payment Type: | T/T,Paypal |
| Incoterm: | FOB |
| Certificate: | CE, ROHS, FCC, UL |
| Transportation: | Ocean,Land,Air |
Product Description
Product Description
Features and Advantages:
PowerProw SRM-Line Solar Charge Controller, it is an advanced PWM Solar Charge Controller, with a power range of up to 15A; automatically read 12 and 24V, SRM-Line Solar Charge Controller can charge your battery quickly and stably under any condition of solar panel array. This new series Solar Charge Controllers are equipped with our latest charging algorithm with advanced PID for accurate control, the multi charging stage has been optimized for long battery life and improve the system performance, this Solar Charge Controller fits the solar panel up to 250W and be suitable for wide applications including lighting, home, traffic, security, RV, caravan, boating, cottage and other back up or remote power uses.
SRM-Line Solar Charge Controller is built with a modern design, the state of charge is represented visually in the large LCD on the top of housing; the users can easily read the battery condition, battery type, charging voltage, charging current and capacity. Friendly interface to be flexibly set the different battery type for AGM, Flooded, Calcium and Gel battery, external temperature sensor is provided, resulting in optimal battery charging performance and battery maintenance in any tough environments.
Multi electronics protections and conformal coating protection for the inside board, as well as provide an additional version with epoxy resin sealed for waterproof, makes the Solar Charge Controller completely maintenance-free and robust.
Electrical Specification:
1. For solar panel 25V Max.
2. Rated current (A) 10A
3. Charge algorithm PWM, Constant voltage.
4. Soft start voltage (V) 10.5V
5. Absorption voltage (V) 14.4/ 14.7 --- Sealed / Flooded Battery version.
6. Absorption voltage (V 14.1/ 14.4 /14.7 /14.9 --- Gel / AGM / Flooded / Calcium Battery version.
7. Equalization voltage (V) 15.5V
8. Float Voltage (V) 13.6V
9. Self-consumption (mA) ≤5<br> Loop Voltage Drop (mV) ≤150
10. Voltage accurancy in LCD NA
11. Current accurancy in LCD NA
12. Temp. Comp. ( mV/°C) -24
General Specification:
1. Compatible battery types Two or four battery types selection (depends on above different versions selected)
2. Storage ambient temperature range (°C) -40~85
3. Operating ambient temperature range (°C) -20~50
4. Dimensions (H x W x D) 130mm X 102mm X 27mm
PowerProw SRM-Line Solar Charge Controller, it is an advanced PWM Solar Charge Controller, with a power range of up to 15A; automatically read 12 and 24V, SRM-Line Solar Charge Controller can charge your battery quickly and stably under any condition of solar panel array. This new series Solar Charge Controllers are equipped with our latest charging algorithm with advanced PID for accurate control, the multi charging stage has been optimized for long battery life and improve the system performance, this Solar Charge Controller fits the solar panel up to 250W and be suitable for wide applications including lighting, home, traffic, security, RV, caravan, boating, cottage and other back up or remote power uses.
SRM-Line Solar Charge Controller is built with a modern design, the state of charge is represented visually in the large LCD on the top of housing; the users can easily read the battery condition, battery type, charging voltage, charging current and capacity. Friendly interface to be flexibly set the different battery type for AGM, Flooded, Calcium and Gel battery, external temperature sensor is provided, resulting in optimal battery charging performance and battery maintenance in any tough environments.
Multi electronics protections and conformal coating protection for the inside board, as well as provide an additional version with epoxy resin sealed for waterproof, makes the Solar Charge Controller completely maintenance-free and robust.
Electrical Specification:
1. For solar panel 25V Max.
2. Rated current (A) 10A
3. Charge algorithm PWM, Constant voltage.
4. Soft start voltage (V) 10.5V
5. Absorption voltage (V) 14.4/ 14.7 --- Sealed / Flooded Battery version.
6. Absorption voltage (V 14.1/ 14.4 /14.7 /14.9 --- Gel / AGM / Flooded / Calcium Battery version.
7. Equalization voltage (V) 15.5V
8. Float Voltage (V) 13.6V
9. Self-consumption (mA) ≤5<br> Loop Voltage Drop (mV) ≤150
10. Voltage accurancy in LCD NA
11. Current accurancy in LCD NA
12. Temp. Comp. ( mV/°C) -24
General Specification:
1. Compatible battery types Two or four battery types selection (depends on above different versions selected)
2. Storage ambient temperature range (°C) -40~85
3. Operating ambient temperature range (°C) -20~50
4. Dimensions (H x W x D) 130mm X 102mm X 27mm
