Laser Engraving Metal Insert Mold For Electric Appliances A
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong,China |
|---|
Laser Engraving Metal Insert Mold For Electric Appliances Accessories
Like the plastic parts production, complex shape of small metal parts (0.1-500 - g)
|
Brief description |
Similar with the plastic parts production, complex shape of small metal parts (0.1g to 500g); Uniform has stamping parts organization, high dimensional accuracy, high relative density (95% or higher); Has good surface finish; |
|
Part name |
Metal injection moulding for precision metal parts |
|
Material |
Stainless steel , Hard alloy , Iron base alloy steel, Nickel base alloy , Titanium alloy , Magnetic materials , Tungsten alloy |
|
Application scope |
Electrical Industry,Healthcare products,Industrial products,Accessory,Mechanical products |
|
Advantage |
1. Cost Effective,Design Felxibility,Material Variety and Integrity 2. Complexity:allow the freedom to manufacture complicated shapes that would be considered cost prohibitive by other methods. 3. Precision:+/-0.3 to 0.5% tolerance. 4. Weight & Size:0.1-500g 5. Section Thickness:0.2-10mm 6. Sintered Density:95 to 100% dense 7. Material Utilization:>98% 8. Production Volumes:allow thousands millions parts,quickly and efficiently. |
|
Surface treatment(Finish) |
Polish,Laser engraving,Brush,Magnetic grinding,Plating,PVD coating |
|
drawing format |
we accept DXF,DWG,IGS,STP,SIDPRT,X_T etc. |
|
MOQ |
Negotiable |
|
Payment Terms |
T/T,paypal,Western Union |
|
Machining Lead-time |
7-15 days, according to the quantity of products |
|
Packing |
Rray, bubble bags, Carton or per customers request |
|
Logo |
Per your request |
Contrast Between MIM and Precision Casting Molding
|
Property |
MIM |
Precision Casting Molding |
|
Minimum Thickness |
0.4mm |
2mm |
|
Maximum Thickness |
10mm |
Unlimited |
|
Minimum Diameter |
0.4mm |
2mm |
|
Tolerance of Diameter 4mm |
+/-0.06mm |
+/-0.2mm |
|
Surface Roughness |
1μm |
1μm |
Description
1. The Metal powder injection molding (MIM) is a high-tech near net shape technology to mass production
of small but precision metal parts with complex structure, high precision and performance requirements.
2. MIM technology has its advantages over than traditional powder metallurgy, CNC machining, investment
casting, and other alternative methods.
3. Derive the stable product quality, production efficiency is high, easy to implement the mass production.
Features to avoid
1.Inside closed cavities
2.Undercuts on internal bores
3.Very shape corners or design-desired radius greater than 0.05mm
4.Long pieces without a draft or taper to allow ejection
Q1. What is MIM technology?
MIM (Metal Injection Molding) is a manufacturing technology that combines the shape making complexity
of Plastic Injection Molding with the material flexibility of Powder Metallurgy.
Q2. Is the metal melted during the molding process?
No, only the binders are melted allowing the powders to flow like a plastic material. Upon cooling the
binders solidify giving the part strength for handling. The part must be subsequently sintered to high
density to achieve the required mechanical properties.
Q3. Does the part shrink during removal of binders?
No, the part will not change size in the debinding phase of the process. However, since sintering achieves
near full density of the powders, the part will undergo a size change of up to 20%.
Q4. Why should I use MIM?
MIM excels in producing small, highly complex parts that are difficult or cost prohibitive to produce with
conventional technologies such as machining or casting.
