Waterproof IP67 12V 30W LED Strip Power Supply With Short - circuit Protection
Description:
1. Protections :Short circuit/Overload/Over temperature
2. Cooling by free air convection
3. IP67 design for indoor or outdoor installations
4. 100% full load burn-in test
5. Suitable for LED lighting
6. Products through CE& ROHS certification
7. Two years warranty
Specification
|
SJ30 - W1V12 | |
| AC input voltage range | 100 - 264 VAC 47 - 63HZ | |
| Input Current | 0.56A / 115V ; 0.28A / 230V | |
| AC inrush current | Cold - start current 30A / 230V | |
| Leakage current | < 3.5 mA / 240 VAC | |
| Over load protection | 115 - 135 % hiccupmode,auto-recovery | |
|
115-135% Cut off the output,auto-recovery | |
| Over - temp protection | ≧ 85% ° c Cut off the output, auto-recovery | |
| IP grade | IP67 | |
| Setup rise hold up time | 200ms 100ms 30ms | |
| Withstand voltage | I / P - O / P: 1.5 KvAC 1 minute | |
| I / P - FG:1.5 KvAC 1 minute | ||
| O / P - FG: 0.5 KvAC 1 minute | ||
| Working temperature | ~ 40° c ~ + 80° c, 20% ~ 90% RH | |
| Weight / packing / Size | 0.25kg, 50pcs / 13.5kg, 217*29.2*20.5mm |
Quality guarantee
a) All products will have been strictly quality checked by test equipment before packing
b) All products will be well packed before shipping
c) All products are 2 years warranty, and we guarantee the products will be free maintenance within warranty period
