New Automatic Stretch Film Machine

1000mm three/five layers fully automatic stretch film unit

The design of this unit is based on the actual manufacturing experience and combine foreign technology.It is suitable for graining CPE, CPP, PP, PE, CEVA cast stretch film , wrapping film, PE preservative film,which using LLDPE as main material to produce two-layer or three-layer one face self-stick stretch film.

Main Technical Parameter:

Model: CL-45/65/55A

Width of Die Head: 1250mm

Width of Film: 1000mm

Thickness of Film: 0.01-0.05mm

Structure of Film Layers: A/B/C or A/ C/B /C/A

Liner Speed of Machinery: 120m/min

Max Extrusion Capacity: 135kg/h

Max Rewind Diameter: 400mm

Screw Diameter: 45/65/55mm

L/D Ratio of Screw: 30:1

Motor Power of Main Machine: 11/18.5/15kw

Total Power: 15.5-65kw

Overall Dimensions(L*W*H): 7.6*4*3.6m

Total Weight: 9.5T

Features:

1. The alloy screw adopts special mixing refining function and high plasticity design , this unit consists of import static state mixer to ensure good plasticity and high quality output.

2. The bi-directional loop design and helix runner inside cooling steel roller is adopted to ensure even temperature of roller surface.

3. Winding roller frame adopt frame adopt aisle-platform, it`s easy to test and adjust the thickness of film, and change the slitter without stopping the machine.

4. The winding system apply air knife online device, which can automatic cut different thickness film.

Application

The film produced by this machine is very good packing film for packing goods, to prevent loosening and anti-dust. etc. The film can be widely used in wrapping of pallet packaging, storage packaging, manual packaging and so on. Perfect transparency and tensile strength of this film keep cargos clean and safe .

Workshop

Certificate

Packing

After-Sales Service

Our professional engineering team is constitutive of excellent technical staff. We can provide perfect after-sales service in time, give a good technical training to ensure the product in best state perennially.

We will respond to customer`s service requests and complaint in the shortest possible time, give a clear reply and solution to deal with in time. At the same time, we sum up customer`s complaint and proposal in order to inherit our advantages, correct our inadequate. We will commit to improve our services quality, so that our customers will be most satisfied.

We offer warranty on product quality and lifelong maintenance services.
