Onboard AMD E350 processor super slim Mini ITX embedded all in one PC motherboard 2 serial ports support VGA / HDMI / LVDS , Wi-fi / 3G , DC power supply
Quick detail
- Integrated AMD E350 1.6GHz dual core Processor
- AMD Hudson D1 Chipset
- Support 1* SO DDRIII 1333/1066MHz, Max. Up to 4GB
- AMD Radeon HD6310 Graphics, support 1080P HD
- Support VGA/HDMI/LVDS display output
- LVDS supports dual 24BIT
- 1* Mini-PCIE, support WIFI/3G
- 1* RTL8111E 10/100/1000Mbps Ethernet,Support Wake-on-LAN and PXE function
- 2* SATAII
- 1* MSATA, support SSD
- Integrated Realtek HD ALC662 for 6-Channel output
- 10* USB 2.0
- 2* RS232
- DC_12VSingle power supply
- Dimension 170mm x 170mm
Appliance
- for All in one PC motherboard
- for HTPC computer
- ATM machine motherboard
- Kiosk Motherboard
- Digital signage motherboard / mainboard
Specifications
|
CPU |
Integrated AMD E350 1.6GHz dual core Processor |
|
Chipset |
AMD Hudson D1 Chipset |
|
Memory |
1* SO DDRIII 1333/1066MHz, Max. Up to 4GB |
|
Graphics |
AMD Radeon HD6310 Graphics, support 1080P HD |
|
|
Support VGA/HDMI/LVDS display output |
|
|
LVDS supports dual 24BIT |
|
Expansion Slots |
1* Mini-PCIE, support WIFI/3G |
|
LAN |
1* RTL8111E 10/100/1000Mbps Ethernet,Support Wake-on-LAN and PXE function |
|
Storage |
2* SATAII |
|
|
1* MSATA, support SSD |
|
Audio |
Integrated Realtek HD ALC662 for 6-Channel output |
|
|
Support MIC/Line-out/Line-in |
|
Rear I/O |
4* USB 2.0 |
|
|
1* HDMI |
|
|
1* VGA |
|
|
1* RJ-45 LAN |
|
|
1* Line Out(green) |
|
|
1* Mic(red) |
|
|
1* 12V DC_JACK input |
|
Internal I/O |
1* LVDS 2*15pin |
|
|
1* JVGA 2*5pin |
|
|
1* JHDMI 2*8pin |
|
|
2* RS232 |
|
|
6* USB 2.0 |
|
|
1* FP1 (2*5pin Front panel buttons and LED connected) |
|
|
1* AUDIO pin (Front Audio interface 2*5pin) |
|
|
1* CD_IN pin Amplifier interface |
|
|
1* CIR 4pin |
|
|
2* PWROUT (Hard drive power connector) |
|
|
1* ATX_12V (Can be used as input and output 12V power connector) |
|
|
1* LVDS INVERTER |
|
Fun interface |
1* CPUFAN and SYSFAN 3Pin |
|
GPIO |
1* GPIO (Support 4-way GPIO function) |
|
BIOS |
AMI 16MB Flash ROM |
|
Watchdog |
Support hardware reset function (L256, 0~255 seconds) |
|
Power Input |
DC_12VSingle power supply |
|
Operating Temp. |
-10°C~60°C |
|
Storage Temp. |
-20°C~70°C |
|
Humidity |
0%-95%(relative humidity; non-condensing) |
|
Dimension |
170mm x 170mm |
