Onboard Intel Celeron 1037U CPU All In One PC Motherboard d
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong,China |
|---|
High End All In One PC Motherboard With Integrated Graphics Support SSD / USB WIFI
Mini-itx embedded All in one PC motherboard 2*COM , 8*USB , 1*VGA , 2*HDMI , 1*LVDS DC power supply support WIFI / 3G
Quick detail
- Onboard Intel®1037U Dual core 22nm Processor (1.8GHZ) TDP 17W
- Intel® HM65 Chipset
- Support 1* SO DDRIII 1333/1066MHz, Max. Up to 8GB
- Intel® HD Graphics
- Offers 1*VGA,2*HDMI,1*LVDS(support Dual 24bit)
- support HDMI1/VGA synchronous/asynchronous display
- support LVDS/VGA synchronous/asynchronous display
- support LVDS/HDMI1 synchronous/asynchronous display
- support HDMI1/HDMI2 synchronous/asynchronous display
- 1* Mini-PCIE, support WIFI/3G (Default WIFI)
- 1* MSATAⅢ, support SSD/USB WIFI(Default USB WIFI)
- 1* RTL8111E 10/100/1000Mbps Ethernet
- 2* SATAⅢ (SATA1 and MSATA with a second election, Default SATA1)
- 1* SATAⅢ 2.5-inch laptop hard place(cannot be used with SATAII at the same time, support laptop HDD)
- Integrated Realtek HD ALC662 for 6-Channel output
- 4* USB 2.0
- 2* RS232, the 9th pin supports +5V/+12V charged function
- 1* SIM
- DC_12V Single power supply
- Size: 170mm x 170mm
Appliance
- for All in one PC motherboard
- for HTPC computer
- ATM machine motherboard
- Kiosk Motherboard
- Digital signage motherboard / mainboard
Specifications
CPU | Onboard Intel®1037U Dual core 22nm Processor (1.8GHZ) TDP 17W |
Chipset | Intel® HM65 Chipset |
Memory | Support 1* SO DDRIII 1333/1066MHz, Max. Up to 8GB |
Graphics | Intel® HD Graphics |
| Offers 1*VGA,2*HDMI,1*LVDS(support Dual 24bit) |
| support HDMI1/VGA synchronous/asynchronous display |
| support LVDS/VGA synchronous/asynchronous display |
| support LVDS/HDMI1 synchronous/asynchronous display |
| support HDMI1/HDMI2 synchronous/asynchronous display |
Expansion Slots | 1* Mini-PCIE, support WIFI/3G (Default WIFI) |
| 1* MSATAⅢ, support SSD/USB WIFI(Default USB WIFI) |
LAN | 1* RTL8111E 10/100/1000Mbps Ethernet,Support Wake-on-LAN and PXE function |
| (It may also support a built-pin card,To be customized) |
Storage | 2* SATAⅢ (SATA1 and MSATA with a second election, Default SATA1) |
| 1* SATAⅢ 2.5-inch laptop hard place(cannot be used with SATAII at the same time, support |
Audio | Integrated Realtek HD ALC662 for 6-Channel output |
| Support MIC/Line-out/Line-in |
Rear I/O | 1* 12V DC_JACK input |
| 1* HDMI |
| 1* VGA |
| 4* USB 2.0 |
| 1* RJ-45 LAN |
| 1* Line out(green) |
| 1* Mic (red) |
Internal I/O | 1* LVDS 2*15pin,support dual 24bit LCD |
| 1* JHDMI 2*8Pin |
| 1* JVGA1 12pin |
| 2* RS232, the 9th pin supports +5V/+12V charged function |
| 1* LPT |
| 4* USB 2.0(If the Mini-PCIE is a USB signal, supports 2 USB) |
| 1* PS/2 6Pin |
| 1* FP1 (2*5pin Front panel buttons and LED connected) |
| 1* AUDIO pin (Front Audio interface 2*5pin) |
| 2* Amplifier Interface 2pin |
| 1* SIM |
| 1* PWROUT (Hard drive power connector) |
| 1* ATX_12V (Can be used as input and output 12V power connector) |
| 1* LAN_LED,4pin |
| 1* LVDS INVERTER |
Fun interface | 1* CPUFAN 4pin 1* SYSFAN 3pin |
GPIO | 1* GPIO (Support 4-way GPIO function) |
BIOS | AMI 32MB Flash ROM |
Watchdog | Support hardware reset function (L256, 0~255 seconds) |
Power Input | DC_12VSingle power supply |
Operating Temp. | -10°C~60°C |
Storage Temp. | -20°C~70°C |
Humidity | 0%-95%(relative humidity; non-condensing) |
Dimension | 170mm x 170mm |
