5150-5850MHz 5GHz 5.8GHz 5.5GHz Grid Parabolic Antenna 30dBi High Gain
  • 5150-5850MHz 5GHz 5.8GHz 5.5GHz Grid Parabolic Antenna 30dBi High Gain
5150-5850MHz 5GHz 5.8GHz 5.5GHz Grid Parabolic Antenna 30dBi High Gain

5150-5850MHz 5GHz 5.8GHz 5.5GHz Grid Parabolic Antenna 30dBi High Gain

Get Latest Price
Payment Type:
paypal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Payment Type: paypal
Product Description
Product Description
ELECTRICAL
Model DT-GPA5150-5850-30
Frequency Range 5150-5850MHz
Gain 30dBi
Beamwidth H: 9° , E: 15°
VSWR ≤1.5
F/B Ratio ≥25dB
Polarization Vertical or Horizontal
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension 600*900mm
Weight 5kg
Mounting Kits L Bracket & U Bolts
Working Temperature -40 ~ + 60℃
Pole Diameter Ф33~55mm
Rated Wind Velocity 60m/s
