Aluminum vacuum coating machine

Get Latest Price

Payment Type:: T/T, Western Union

Incoterm:: FOB, CFR, CIF

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 45 Days

Transportation:: Ocean

Port:: Shekou, Yantian

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen
Productivity:	60
Supply Ability:	9
Payment Type:	T/T,Western Union
Incoterm:	FOB,CFR,CIF
Certificate:	ISO,CE
Transportation:	Ocean
Port:	Shekou,Yantian

Product Description

Aluminum vacuum coating machine

Metal wire (aluminum) physical violence, melting and evaporation of the vacuum chamber, attached to the resistance wire. The vaporized metal molecules are deposited on the substrate to obtain a smooth film and a high reflectivity. Thus, the surface of the article can be made and beautified.
Key words: reasonable structure, fast film forming speed, pumping speed, short cycle time, high efficiency, easy operation, low energy consumption, stable and stable performance.
Industrial, PET, nylon, metal, Boli, glass, ceramic, TPU
Electroplating effect: the general plating surface, dumb (half mute, all dumb), electroplating process wrinkles, lighting processing, raindrops seven colors;

Color: gold, silver, red, blue, green, purple, multi-color and so on.

Technical parameter:

Mode Dimension	HYJ-1214	HYJ-1416	HYJ-1618	HYJ-1820
	1200*1400mm	1400*1400mm	1600*1800mm	1800*2000mm
Film Type	Semitransparent film, non-conducting film, gold, silver, red, blue, green, purple, seven color, etc.
Power source Type	Thermal evaporation power, ion bombard power, RF power
Vacuum chamber structure	Vertical double/single door, horizontal single door, pump system postposition
Ultimate vacuum	8.0*10-4Pa
Vacuum system	Diffusion pump +Roots pump +Mechanical pump +Holding pump
Pump time	Pump from atmosphere to 5.0*10-2,6 minutes
Workpiece motion mode	Public rotation/Frequency control
Control mode	Manual/Automatic all-in-one mode, Touching screen+PLC
Remark	We can design the dimension of the vacuum chamber according to customer`s demand.
