UV Painting Line for Vacuum Metalization Coating

About UV Painting Line
Our UV painting line is compatible with both plastic and metal products painting treatment such as plastic frames, food cans, furnitures, art works and so on. It's especially useful in vacuum metalizing coating spray. Once done, the surface will be formed bright thin coating. UV coatings can be formulated up to 100% solids so that they have no volatile component that contributes to pollution. This high solids level also allows for the coating to be applied in very thin films. UV coatings can be formulated to a wide variety of gloss ranges and can be applied via most conventional industrial coating applications as well as by silkscreen.
Specifications
Button control system by PLC
IWATA or Devilbiss spray guns
Long life cycle Pramarc UV lamps
Accurate temperature & energy control
Manual or 100% automatic spraying
Fast curing and drying

We have a team of genius in spray coating industry. They design and produce via leading concepts and technologies. Our uv coating line comes with advanced layout and long life cycle. You will maintain the equipment with the least effort in short time.

Line size by design
Power 50~100KW(380V,3phase,50HZ)
Workflow Electrostatic de-dust -> spray painting -> Flash off -> Dry oven -> Cooling
Chain conveyor system
Aluminium fixture block
Chain transit unit
Steel alloy track
Inverterters & gear motor
Spray booth
Size:3.35*2.5*2.8m
Stainless steel machine body
Stainless steel water tank
Explosion-proof lighting system
HEPA Filter
Exhaust fan,Air volume-1200 m³/hr
With explosion proof glass  observation window
Rotation unit
Selt-rotation sysem 2 sets
Auto spray gun hold(with scale)
Selt-rotation motor
Magiceye sensor
DEVELBISS spray gun 6 sets
Oven
IR tunnel oven and UV machine
TEM:50-150 degree
Heating pipe and UV lamp
Mirror stainless steel inner wall
T50mm rock wood thermal insulation
China motor
OMRON Temperature card
Control system
PLC touching screen
air switch & overload ensure
Branded power switch & indicator light
Branded pneumatic elements & Magnetism valve
Branded frequency speed controller
Air supply
Blowing Rate15000m³/hr
Machine size:1.2*2.1*1.16m
T50mm sandwich steel panel  machine body
China motor
Taiwan frequency converter
Filtering units
Ventilation
Inlet fan(Direct drive motor):Adopt big inpeller turbo fan,7.5KW,380v,50HZ,CE
2,Outlet fan(Direct drive motor):No
3,Painting and baking exchang system:Solenoid valve+pressure adjustment contol cylinder driven damper exchange
4,Fan Capacity:15000m³/hr
5,Air Flow Speed:0.23m/s in empty booth,0.25-0.35m/s in loaded booth
Support Life time free tech support

UV painting line workflow:
Onloading -> Electrostatic Dedusting -> pre-heating -> base coat spray -> flash off -> UV curing -> Vacuum metalizing -> UV top coat spray -> IR oven -> UV curing -> Cooling -> Unloading -> QC checking -> Packing
Packaging & Shipping
When the machine is shipped, it is in un-assemble condition. Standard packing for exporting requirement. Normally by thin film and wood box. Can be custom packed to meet up with local policies. The solid packing can make sure you will receive a machine without destroy.
