LED BAR DC12v SMD5630 led rigid strip light

  Product Description      LED BAR DC12v SMD5630 led rigid strip light

5630-72LEDS/M ALUMINIUM LED BAR/LED RIGID BAR
ITEM NO.	CHIP	VOLTAGE	POWER	IP RATE	LUMEN	UNIT
JYX-5630-72-AL10-W1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	35-40LM/LED	METER
JYX-5630-72-AL10-WW1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	35-40LM/LED	METER
JYX-5630-72-AL10-B1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-R1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-G1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-Y1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-W1	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	9-10LM/LED	METER
JYX-5630-72-AL10-WW2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	9-10LM/LED	METER
JYX-5630-72-AL10-B2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-R2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-G2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5630-72-AL10-Y2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
5730-72LEDS/M ALUMINIUM LED BAR/LED RIGID BAR
ITEM NO.	CHIP	VOLTAGE	POWER	IP RATE	LUMEN	UNIT
JYX-5730-72-AL10-W1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	35-40LM/LED	METER
JYX-5730-72-AL10-WW1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	35-40LM/LED	METER
JYX-5730-72-AL10-B1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-R1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-G1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-Y1	1 CHIP	12V	36W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-W1	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	9-10LM/LED	METER
JYX-5730-72-AL10-WW2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	9-10LM/LED	METER
JYX-5730-72-AL10-B2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-R2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-G2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5730-72-AL10-Y2	1 CHIP	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER

       Product Features: 1.Easy installation with mounting clip 2.Solid-state, high shock/vibration resistant 3.High brightness and low power consumption 4.Vivid lighting color 5.Defending electricity leakage 6.Aluminum housing, fast heat radiation 7.Can be designed according your requirements, especially we can design the products 8.According the varieties of the pearls and jewels to show your jewels in best way 9.Can adjust the view angle of the LED rigid bar according your counters     Specifications:   1.Model: JYX-5630-72-12v-LED BAR 2.Size:L100cm(1M)xW1.2cm  3.PCB Type:Aluminum 4.Chip Type:3chips/1chip 5.Working Voltage: 12V DC 6.LED Quantity:72 leds/m ,200m/carton 7.View angle: 120 ° ~ 140 ° 8.Working Temperature: -20 ° to 50 ° 9.Life Span:50000 hours 10.Color: W/WW/B/G/R/Y Warmly Note:difference of Chip and FPC One chip means just 1 led in it,and 3chips are 3leds in it.Usually it is not obviously,but when you light the strip on ,you can see it clearly. The strip with double layer FPC is much better than the one with single layer FPC,Usually double layer's back color is white,single is yellow.       Products Pictures:      Packaging & Shipping             Package include:   5630 led bar(not include power supply and controller)     Application:   1.Ideal for decoration of building outlines, landscape illumination, amusement themes. 2.Holiday light sculpture, decorative figure, active signs, displays, shop windows. 3.And storefronts, bar, nightclub, street, sidewalk, deck, park, porch, staircase, railing, ceiling, or driveway.     Our Services       wholesale SMD5630 led bar light 1.Your inquiry related to our products or prices will be replied in 24hours. 2.Well trained and experienced staffs to answer all your enquiries in fluent english. 3.OEM&ODM,any your customized of led flexible strip or other series of led lightings,we can help you to design and put it into production. 4.Distributorship are offered for your unique design and some current models. 5.Protection of your sales area,ideas of design and all your private information.     Company Information         Certificates         FAQ        1. Can I get the samples for free? --We welcome the clients buy samples for evaluation, but you have to pay the cost. There are so many clients need samples before the order, it is a big cost. Thanks for your understanding.
2. Can our logo or a simple parameter printed on the label of the led flexible strip?
--Yes,it is ok.
3. Can you make the lamps using other brand led chip, e.g. CREE, OSRAM?
--Yes, it is ok for other brand chips.
4. Can the carton make in accordance with our requirement?
