New products 2015 innovative product 12v 14.4w/m outdoor led garden lights rgb led power supply strip lights

New products 2015 innovative product 12v 14.4w/m outdoor led garden lights rgb led power supply strip lights       Product Description      Parameters

Brand Name	Jingyuxin lighting
Item Type	Flexible Light Strip
Model Number	JYX-5050-60-12V-IP20
Leds Qty	60leds/m
IP Grade	IP20 non-waterproof
Input Voltage	DC 24V
Lamp power	14.4W/m
Lamp Lumen	10-12lm/led
CRI(Ra>)	65
Working Temperature	-70
Working Lifespan	50,000hrs
Lamp Body Material	Copper
Package Length	5m/roll
Pcb width	10mm
Pcb thickness	2 oz
Chip type	3 chips
Color of reel	black
Color of 3M tape	white/yellow
Certification	CE, EMC, RoHS
Wires way	both sides connect red/black wires

    Features  1.Energy-saving, save up to 70-80% power than fluorescent tubes 2.Ultra-slim, only 2.7mm thickness 3.Refined workmanship with good corner seam joint 4.Excellent thermal management and refined aluminum, lengthen the lifespan of LED light 5.Long lifespan, more than 5 years 6.Good lighting consistency, no dark spot 7.New high-efficiency (95%) constant current driver, which can work under unstable voltage   Products & Applications 1.Cover lighting 2.Architectural lights for canopy, corridors, windows and archways 3.Backlight or edge lighting for signage 4.DIY lights for home use 5.Path and contour marking 6.Decorative lights for holidays, events, shows, exhibitions
     30led 5050 led strip , 60led double pcb 5050 led strip , 60led single pcb 5050 led strip

5050-30LEDS/M DOUBLE PCB LED strip light
ITEM NO.	CHIP	VOLTAGE	POWER	IP RATE	LUMEN	UNIT
JYX-5050-30-D-3-W	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	10-12LM/LED	METER
JYX-5050-30-D-3-WW	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	10-12LM/LED	METER
JYX-5050-30-D-3-B	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-30-D-3-R	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-30-D-3-G	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-30-D-3-Y	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-30-D-3-RGB	3 CHIPS	12V/24V	7.2W/M	IP20/IP33/IP44/IP65	/	METER
5050-60LEDS/M DOUBLE PCB LED strip light
ITEM NO.	CHIP	VOLTAGE	POWER	IP RATE	LUMEN	UNIT
JYX-5050-60-D-3-W	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	10-12LM/LED	METER
JYX-5050-60-D-3-WW	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	10-12LM/LED	METER
JYX-5050-60-D-3-B	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-D-3-R	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-D-3-G	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-D-3-Y	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-D-3-RGB	3 CHIPS	12V/24V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
5050-60LEDS/M SINGLE PCB LED strip light
ITEM NO.	CHIP	VOLTAGE	POWER	IP RATE	LUMEN	UNIT
JYX-5050-60-S-3-W	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	10-12LM/LED	METER
JYX-5050-60-S-3-WW	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	10-12LM/LED	METER
JYX-5050-60-S-3-B	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-3-R	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-3-G	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-3-Y	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-3-RGB	3 CHIPS	12V	14.4W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-1-W	1 CHIP	12V	4.8W/M	IP20/IP33/IP44/IP65	5-6LM/LED	METER
JYX-5050-60-S-1-WW	1 CHIP	12V	4.8W/M	IP20/IP33/IP44/IP65	5-6LM/LED	METER
JYX-5050-60-S-1-B	1 CHIP	12V	4.8W/M	IP20/IP33/IP44/IP65	5-6LM/LED	METER
JYX-5050-60-S-1-R	1 CHIP	12V	4.8W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-1-G	1 CHIP	12V	4.8W/M	IP20/IP33/IP44/IP65	/	METER
JYX-5050-60-S-1-Y	1 CHIP	12V	4.8W/M	IP20/IP33/IP44/IP65	/	METER


    Packaging & Shipping      Packing details: Anti-static bag:  Unit Type:lot (5 meter/roll) Package Weight:0.8kg   Package Size:30cm x 22cm x 7cm  Carton details: a.100 rolls in one carton for IP20(non-waterproof)  b.50 rolls in one carton for IP65(waterproof) Carton size: 48*28*22cm
     Shipping details: 1. We ship goods to worldwide.  2.All the order will be ship out in 2-7days, usually we ship the goods in 24hours after receipt of payment.  3. We only ship to the address that is provided by  the alibaba, so pls make sure thatyour address is correct and up to the date.We are not responsible for the wrong or undelivery address. 4.Item can be shipped by our choice of our carriers of EMS/DHL/UPS/Fedex/ TNT /China Post /Hong Post post/Sweden Post ect. we will provide you TRACKING NO on your order. Ifyou have special request about the shippment, you can contact us or leave message, we will try to satisfied with you.   Our Services   1. Your inquiry related to our products or prices will be replied in 24hours. 2. Well trained and experienced staffs to answer all your enquires in fluent English.
3. OEM&ODM, any your customized of led flexible strip or other series of led lightings we can help you to design and put into production.
4. Distributorship are offered for your unique design and some our current models.
5. Protection of your sales area, ideas of design and all your private information.     Company Information   1.We are a large-scale lamps manufacturing enterprise  2.We specialize in producing Led Strips lighting and LED bar.  3.We focus on Quality manufacture our lights in accordance with CE,GS, RoHS certification 4.We meet and exceed global quality standards 5.We now ship well over half of our output to countries and regions worldwide           FAQ   1. Can I get the samples for free?
--We welcome the clients buy samples for evaluation, but you have to pay the cost. There are so many clients need samples before the order, it is a big cost. Thanks for your understanding
2. Can our logo or a simple parameter printed on the label of the led flexible strip?
--Yes,it is ok.
3. Can you make the lamps using other brand led chip, e.g. CREE, OSRAM?
--Yes, it is ok for other brand chips.
4. Can the carton make in accordance with our requirement?
--Yes     Contact us Brian Qiu QQ:  1536543604 Phone&WhatsApp&Wechat: 0086-13641413026 E-mail:brian@jyx-led.com  Skype ID:brainqiu106     Your inquiry will be replied within 24 hours. Thank you very much for view this page, and wish you a nice day!
