80x80x20mm YOFOLON DC8020S12H 12V high rpm flow DC Cooling Fan

  Product Description 80x80x20mm  YOFOLON DC8020S12H 12V high rpm flow DC Cooling Fan Size: 80X80X20mm Frame: Plastic Impeller: Plastic P. B. T. Voltage:12V, 24V Current: 0.07~0.20A Power: 1.20W~2.88W Speed: 2200~3200RPM Air flow: 24.32~33.85CFM Pressure: 1.68~3.26(mmH2O) Noise: 24.34~31.56dBA Bear type: Sleeve, Two Ball are Available Weight: 63G Motor: Brushless DC, auto restart Impedance & polarity protected Operation temperature: -20° C~80° C Insulation Resistance: 10 At 500VDC between lead and frame Dielectric Strength: 1 min at 500VAC/50-60Hz, current min 5mA Operation Humidity: 20%~85% Working voltage: Rated voltage± 15% Life at 25oC: Ball bearing 50, 000hrs and sleeve bearing 30, 000hrs       Motor Protection (Selective purchasing): 1.Automatic Restart. 2.Reverse Polarity Protected 3.Water proof for IP25, IP55 4.IC function RD ,FG and PWM control are available   * Two ball bearing applying * Applying NMB ball bearing inported from Japan * Short lead time 1 Week after confirm order Packaging & Shipping     FAQ       Company Information
