High Quality Low Loss Low Pass Original Power Line AC Filter

High Quality Low Loss Low Pass Original Power Line AC Filter Product Description Specification

Item	AC Filter
Model	AC Filter -YX82H4
Transfer Function	Low Pass
Package Type	Surface Mount
Nominal Center Frequency	10K-30MHZ
Insertion Loss	60~90dB
Input Impedance	50Ω
Rated Voltage	380V/4400V
Rated Current	1A-800A
Environmental Temperature	40°C
Temperature Range	25 / 085 / 21
Operating Frequency	50/60HZ
Line to Line	1450VDC
Line to Ground	2250VDC or 2000VAC
Maximum Leakage Current	115VAC/60HZ     1.2mA Max.     250VAC/60HZ   2.4mA Max
MOQ	500pcs
Price	USD43~52/Meter
Lead Time	5~15 weekday for AC Filter

  ELECTRICAL Schematic Elec   Outline dimension drawing Pictures     Certificate Packaging & Shipping   Packaging AC Filter: CTN/10pcs N/G W.: 12/13.6KG Measures: 0.565*0.285*0.205 m   Shipment ---Shipping terms: DHL, UPS, FEDEX, TNT, EMS ---Port is Shenzhenor as requests. Our Services     Sample
Sample Fee: Negotiate
Sample Time: 3~5 days

Payment
---Payment terms: Western Union, D/P, T/T,L/C
---Please remember to leave the correct contact information for delivery.   Company Information    1. Integrates development, manufacturing and sell in-house
2. Quality assurance and certification: ISO 9001 CE  ROHS
3. Yearly capacity: 600000-1000000 pcs
