IP54 IP Rating Ra80 36w 600x600 led flat panel lighting

IP54 IP Rating Ra80 36w 600x600 led flat panel lighting Specification You are here: Home > Product Categories > Edge-lit LED Panel Light > 600x600 LED Panel Light   You may also be interested in below products. Click the pictures to view more:
                                       IP54 IP Rating Ra80 36w 600x600 led flat panel lighting
CE TUV Certified Power Supply and Epistar SMD2835 LED Chip Mitsubishi Light Guide Plate   The Specifications of  600x600 LED Flat Panel Lighting

Model No	LM-P606036	LM-P606040	LM-P606048	LM-P606054
Power Consumption	36 W	40 W	48 W	54 W
Luminous Flux (Lm)	2880-3240 Lm	3200-3600 Lm	3840-4320 Lm	4320-4860 Lm
LED Qty(pcs)	192 pcs	192 pcs	252 pcs	300 pcs
LED Type	SMD 2835
Color Temperature (K)	2800 - 7000K
Color	Warm White/Pure Whitel/Cool White
Dimension	595x595x9mm
Beam Angle (degree)	>120°
Light Efficiency (lm/w)	>80lm/w
CRI	>80
Power Factor	>0.95
Input Voltage	AC 85V - 285V
Frequency Range (Hz)	50 - 60Hz
Working Environment	Indoor
Material of Body	Aluminum alloy frame and PC cover
IP Rating	IP54
Operating Temperature	-20°~65°
Dimmable	Optional
Life span	50,000hours
Warranty	3 Years

      What are the advantages of Lightman 600x600 LED Flat Panel Lighting?
• Superior Aluminum Alloy materials. Stylish everlasting color aluminum frame with advanced anodized and oxidation treatment. Advanced designing makes the ceiling lighting more elegant.
• Different sizes of LED light panel for your options. Diversity in shape (square, rectangle)
• Easy to install. Ideal to be built into system ceilings, offices, and can be used as a hanging fixture.
• LED flat panel light direct replace T8 and T5 fixtures.
• Lightman LED panel light is with high efficiency, maximum uniformity by Mitsubishi Light guide plate.
• The beam angle of led panel light is120°.
• Innovated structure heating design.
• EVA foam protects the led panel light guide plate from reshaping.
• Constant current driver with a power factor of 0.95;
• Lock cable DC plug for led flat panel light.
• LED panel lights are CE, ROHS, FCC, TUV, GS, CB, SAA, PSE and EMC certified.   Product Details
