1214x300mm 1'x4' new modern ultrathin and non-leakage led flat panel lighting Specifications You are here: Home > Product Categories > UL&DLC LED Panel Light > 1ft x 4ft LED Panel Light                   1214x300mm 1'x4' new modern ultrathin and non-leakage led flat panel lighting
  The Specifications of 1ft x 4ft /300x1200 led panel light:

Model No	PL-1x4-36W	PL-1x4-40W
UL/DLC Model	ET-14-36WD	ET-14-40WD
Power Consumption	36 W	40 W
CW/NW Light Efficacy	106lm/w	103lm/w
WW Light Efficacy	103lm/w	101lm/w
Dimension (mm)	300x1214x10mm
Color Temperature (K)	3000K/3500K/4000K/4500K/5000K
LED Type	SMD 2835
Input Voltage	AC100-277V, 50/60Hz
Beam Angle (degree)	>120°
CRI	>80Ra
Power Factor	>0.95
THD	<15%
Working Environment	Indoor
Material of Body	Aluminum Frame + Mitsubishi LGP + PS Diffuser
IP Rating	IP20
Operating Temperature	-20°~65°
Dimmable	0~10V(UL)/ Dali/ PWM/ Triac Optional
Installation Option	Ceiling Recessed/ Suspended/ Surface/ Wall Mount
Life span	60,000hours
Warranty	5 Years

  What are the advantages of Lightman LED Panel Light?
•110lm/W high lumen efficacy, with high CRI more than 80Ra, energy saving LED panel.
•UL, DLC, Lighting Facts, FCC certified.
•LM80 26x46mil 2835 SMD, 97.1% lumen maintenance @ 6,000 hours.
•Electrophoresis technology provides white appearance, with superb heat dissipation performance.
•EnGap technology ensures the high lumen efficacy and protection of the LEDs.
•LGP expansion test, UV yellowing-proof test and the back plate light-leaking make  sure the high quality.
•Driver 100% 12h aging test and pre-delivery inspection ensure the stable performance.
•Dimmbale: 0-10V dimming for option.
•5 years warranty.
•Easy to install by special design safe lock. Product Details

Product Application Installation&Packing
