Low temperature of minus 40 degrees frozen cabinet

  1) The main system uses low-temperature environment-friendly French imports Taikang compressor, auxiliary system uses low-temperature environment-friendly domestic Bo Yang compressor, copper tube evaporator, the overall security power: 5.5KW, 220V / 5N / 50HZ; 2) the use of PU insulation layer, the thickness of the insulation layer is 120MM, strong support hinges, strong and durable; frozen food center temperature from + 70 Celsius  ~ -18 Celsius  dual refrigeration refrigeration process fast and efficient cooling. Inside temperature ≥-18 Celsius  after saving stand-alone refrigeration system, the entire process of staged cooling methods to ensure no loss of nutritional food, fresh taste, fast plasticity effects.
3) computer temperature delay protection, stable operation, cooling speed, removable door seal and door frames heating wire, freezing temperature ≥-40 Celsius and low temperature refrigeration evenly inside the cabinet, allowing the cabinet temperature difference within the national standard range; export only accessories (including Hong Kong, Macao, and Taiwan). 4) whole body made of stainless steel, beautiful and durable, zinc outer top and bottom back plate.
5) The use of environmentally friendly refrigerants machine cryogenic refrigerant R404A.
6) The machine adopts intelligent power-saving system, when the temperature reaches the set temperature, the compressor stops running, in order to achieve the highest energy saving effect.
7)  Each door put 11 600 * 400 mm discs     1) the second set of refrigeration system, the main system using low temperature environmental France imported taikang compressor, auxiliary system adopts low temperature environmental protection domestic compressor unit, pure copper tube evaporator, a single machine power is about: 3.1 KW, 220 v / 3 n / 50 hz (optional) 380 v;   2) using PU insulation, thermal insulation layer thickness is 120 mm, strongly support the door hinge, sturdy and durable; Quick-frozen food center temperature from 90 ℃ ~ + - 5 ℃ double machine efficient rapid refrigeration refrigeration cooling process. Temperature inside ark - 30 ℃ or less after the single machine running refrigeration system energy-saving, the whole process can adjust human stage cooling way, to ensure that the nutrition of the food, the taste is fresh, fast plastic effect. 3) computer temperature control delay protection, stable operation, fast refrigeration, removable door and doorcase fever wire, freezing temperature and 40 ℃ or higher internal cooling uniformity and low ark, allowed inside temperature difference within the scope of the national standards; Export only provide fittings. 4) the whole airframe adopt stainless steel, beautiful and durable, or back to zinc plate. 4) the whole airframe adopt stainless steel, beautiful and durable, or back to zinc plate.
5) this machine refrigerant use environmental protection refrigerant R404A at low temperature.
6) the machine adopts intelligent power saving system, when the temperature reaches the set temperature, the compressor is shut down, in order to achieve the highest energy saving energy saving effect.
7) each door delivery 1 11 layers trolleys, stainless steel distribution L * D * H = 600 * 400 * 38 mm stainless steel punching plate of 11.
Cryogenic tank series of quick-frozen ark is its extremely fast cooling speed and large temperature difference than (about is the effect of ordinary refrigeration equipment more than 10 times), can let food quickly through 0 ℃ ~ 5 ℃ maximum growth bands, avoid the cell walls of ice crystals to Pierce, reduce the outflow of SAP, maximum limit save food flavor and nutrition. Plate shelf freezer examples: 1. The main technical parameter freezing capacity: 1000 kg / 2 times. The number of tablet: effective put 10:10 layer (3) tablets effectively put size: 2100 mm * 1200 mm (length * width) flat net spacing: 120, body size: 2700 * 1700 * 2130 mm 4. Nominal refrigerating capacity: 43.26 KW (R404A, evaporation temperature 30 ℃
