Low speed mini dc gear motor LT16GA030 6v dc motor for medical device
- Delivery Time:
- 25 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|
LT16GA030061500 data sheet Reduction ratio | 11 | 22 | 33 | 50 | 83 | 100 | 150 | 200 | 300 | 450 | 600 |
Gearbox L mm | 11 | 11 | 12.5 | 12.5 | 14.2 | 14.2 | 14.2 | 15.6 | 15.6 | 15.6 | 17.0 |
No load speed rpm | 1360 | 682 | 454 | 300 | 180 | 150 | 100 | 75 | 50 | 33 | 25 |
Rated speed rpm | 1020 | 511 | 340 | 225 | 135 | 112 | 75 | 60 | 35 | 25 | 18 |
rated torque kg.cm | 0.048 | 0.096 | 0.144 | 0.22 | 0.33 | 0.40 | 0.54 | 0.72 | 1.07 | 1.46 | 1.95 |
Max Torque kg.cm | 3 | 3 | 3 | 3 | 3 | 5 | 5 | 5 | 5 | 5 | 5 |
Factory View:
