150M Wireless Networking Router Signal Booster Access Point Wifi FDD TDD Modem

Product Description

Product Name	150M Wireless Networking Router Signal Booster Access Point Wifi FDD TDD Modem
Band/Mode	TDD-LTE: B38/39/40/41 FDD-LTE: B1/B3/B5/B7/B8/B20/B28 TD-SCDMA: B34/39 UMTS:B1/B2/B5/B8 GSM Quad Band
802.11b/g/n	802.11b mode 802.11g only mode 802.11n only mode 802.11b/g only mode 802.11b/g/n mode 802.11n 1x1 (2.4GHz, 20MHz)
Antenna	4G/3G/2G Main antenna, 4G MIMO/3G Rx Diversity antenna, WiFi antenna
SIM Card slot	Standard 6 PIN SIM card interface, compliant with 3GPP 31.101 and 31.102
RF Power	Class 4 for UMTS/HSPA/LTE;
Functions	4G to wifi, QoS and PS, forwarding data to and from WAN,VPN Pass-through
LED Screen	Wifi, user amount, battery, Messasges

Products Show Features: WLAN: 802.11 b/g/n
5 seconds fast boot ,one touch connection
10 Wi-Fi enabled devices connection at the same time
Speed up to 100Mbps/50Mbps(theoretical value)
Built-In Battery 2400mAH
Support Windows XP/Vista/Win7,Win8,Mac OS,Andriod

Model: M806
Mobile WiFi Network: FDD/TDD LTE/HSPA+/UMTS+GSM

B1(2100MHz)/B3(1800MHz)/B5/B7(2600MHz)/B8(900MHz)/B20(800MHz) (Optional);
TDD LTE B38/B39/B40/B41
B1(2100MHz) / B8( 900MHz)or B1(2100MHz)/ B5(850MHz)(Optional)
B5(850MHz)/B8(900MHz)/B3(1800MHz)/B2(1900MHz)

Speed
LTE DL:100Mbps,UL:50Mbps
HSPA+/UMTS DL :42/21.6/14.4/7.2Mbps,UL:5.76Mbps/384Kbps

Battery:  2400mAh
Dimensions: 100mm*60mm*16mm,Weight:100g(With Battery)
