Thermal Conductive Gap Pad

Specifications 1.Thermal conductivity can reach 2.5 W/mK

2.High flexibility

3.Excellent autohension

4.Easy to operate, can be used repeatly.

  Product introduction   MTB - P2500 is a soft gap filling thermal conductive gaskets, because of its rather softbess can make it in the case of low pressure showed with low thermal resistance. Remove between components and circuit board air at the same time, and full fill all kinds of rough surface. Operate easily and can be repeatly used.       Characters   Thermal conductivity can reach 2.5 W/mK   High flexibility   Excellent autohension   Easy to operate, can be used repeatly.

TYPICAL PROPERTLES OF MTB-P1500
PROPERTY	TEST VALUE	TEST METHOD
Color	Bright Yellow	By Eyes
Thickness Range1	0.02"-0.32" (0.5-8mm)	_
Specific Gravity	2.9g/cc	Helium Pyncometer
Hardness(Shore OO)	28	ASTM D2240
Tensile Strength	26 psi	ASTM D412
Usage Temperature Range	—50°Cto 200°C	Darbond
UL Falmmability Rating	94 V0	UL94
ELECTRICAL
Thermal Conductivity	2.5 W/mK	Hot Disk
Thermal Resistance @3.5mm,10psi	0.528°C—in2/W	ASTM D5470
ELECTRICAL
Dielectric Breakdown Voltage?	≥6.0 KV/mm	ASTM D149
Volume Resistivity	3.2×10 16 Ohm-cm	ASTM D257

      Thickness tolerance,in(mm)±10% nominal thickness or less   Application   Graphic display, LED lighting equipment, Power conversion equipment,high thermal conductivity requirements of power supply module, Communication equipment, Household appliances, Memory storage module, PC server/workstation, Car engine control unit, Computer heat dissipation module, Large storage drive at a high speed       Package   The standard size is 200mmx400mm,300mmx300mm,and we can do the package as your designs.       The standard thickness is 0.3mm  0.5mm 1.0mm 1.5mm 2.0mm 2.5mm 3.0mm 3.5mm 4.0mm 4.5mm 5.0mm
