3.7v 7000mah lipo battery,rechargeable prismatic battery customize
Your message must be between 20 to 2000 characters
Contact NowPlace of Origin: | Guangdong, China (Mainland) |
---|
Nominal voltage | 3.7v |
Nominal capacity | 1000mah |
Battery cell | 3.7V 1000mah li-polymer battery |
Dimension | Customized |
Cycle time | 500 times |
Charging cut-off voltage | 4.2V |
Discharge cut-off voltage | 3.0V |
Maximum constant charging current | 0.5C |
Maximum continuous discharging current | 1C |
Operating Temperature | Charge 0~45°C Discharge –20~60°C |
Storage Temperature | -20~45°C for 1Month -20~35°C for 6Months |
Storage Voltage | 3.80-3.90V |
Standard Model | Standard Capacity | Nominal | Dimension(mm) | Approx. Weight | ||
T (±0.2) | W (±0.5) | H (±0.5) | ||||
041124 | 80 | 70 | 4.0 | 11 | 24 | 1.2 |
051215 | 50 | 40 | 5.0 | 12 | 15 | 1.0 |
621221 | 100 | 90 | 6.2 | 12 | 21 | 2.3 |
041225 | 80 | 70 | 4.0 | 12 | 25 | 1.4 |
051225 | 100 | 90 | 5.0 | 12 | 25 | 2.3 |
041235 | 120 | 100 | 4.0 | 12 | 35 | 2.3 |
451235 | 130 | 120 | 4.5 | 12 | 35 | 2.7 |
051235 | 150 | 140 | 5.0 | 12 | 35 | 4.0 |
551235 | 160 | 150 | 5.5 | 12 | 35 | 4.5 |
061235 | 170 | 160 | 6.0 | 12 | 35 | 4.8 |
651235 | 190 | 180 | 6.5 | 12 | 35 | 5.0 |
Remarks: Please contact us on customized size, and minimum order may require. |
