Joint Brand 3 axis CNC Milling Machine GSK controller for sales

Joint Brand 3 axis CNC Milling Machine GSK controller for sales Features 1.Taiwan high precise NC milling head,Inverter and variable speed. 2.Processing accuracy 0.02-0.03mm.
3.OEM Manufacturer.   4.High quality Mehanite cast,ageing treatment.
5.Design of the overall enhanced ram.   6.Milling head and the machine body scrapped accordingly to assure high accuracy.   7.Great touching area exists between integral bending arm and milling head,assure stability and long-time accuracy.   8.There is no need for belt or gear shift operation.Operators can operate the hand wheel on the milling head to change speed.   9.Spindle speed is changed through CNC system controller. Specification: NC Milling Machine 4KJ-B

Model	4KJ-B
Table size	1270*254*90mm
T-slot(W*N*D)	16*3*65mm
X axis travel	710mm
Y axis travel	340mm
Z axis travel	105mm
Knee travel	340
Max. distance from the spindle nose to table	0-400mm
Spindle rated power	3HP(2.2KW)
Spindle taper	R8/NT30
Rotation speed	80-4530 (16 speed)
Rapid feed speed(X/Y/Z)	5/5/4 m/min
Three axis feed speed	2 m/min
Dimension	1500*1700*2150mm
Weight	1400kgs

      1.Standard accessories: Clamping kits 6" Vise Working light Coolant system Table Guard   2.Optional accessories: Milling chuck Power bar The 4th axis     After-sales services: Warranty is a year, we would offer the parts( quality problem) free of charge  during this period. Overseas service need to be charged extra.     1.Plant:       1.Research and Development team: We have a large group of Research and Development team , they own the professional theory knowledge, special technology skills and rich experience in the technical research field.    2.Certificate and Honour: 1.8 Intellectual property rights and 5 the patents 2.The self-owned brands of JOINT,NC-JYD have become the famous and high-quality mark in Chinese machinery field. 3.From 2004 to 2007,we have been granted with “Top 100 Metal Cutting Machine Tool Manufacturers” in China. 4.In 2011,we have been granted as "National Grade HI-Tech Enterprise". 5.We have introduced ISO9001:2008 in 2009. 6.The turret Vertical milling machine,NC knee type milling machine and Vertical machine center and Surface grinding machine has obtained CE certificate notified by CCQS.      3. Production lines        FAQ Q: Are you trading company or manufacturer ? A: We are factory. Q: How long is your delivery time? A: Generally it is 5-15days if the goods are in stock. or it is 10-15 days if the goods are not in stock, it is according to quantity. Q: What is your terms of payment ? A: 30% in advance.and the rest payment should pay before delivery.   Q: How many years have your company established? A: 20 years, our company built in 1995.
