High quality CNC milling machine VMC-850L3

High quality and high precision CNC Machine center VMC-850L3 Vertical Machine Center
Hardned & quenched slideway with Turcite B coated,
Imported ball screw
Ranishaw Laser testing syst

  Features: 1. Mehanite casting,computer analysis facilities are used in its manufacturing,    wide distance slide way makes outstanding rigidity. 2.Pre-pressed and pre-tense double screw assures feeding high accuracy.    Special design of slide way and auto lubrication system ensures the accuracy    long-time of the machine. 3.Precisely scrapped and Turcite B coated slide way makes machines run smoothly. 4.X,Y axis are assembled with linear way, Linear device is closely fixed on the cast   Who has the features of small touch area,small friction;hence each machine embodies   Quickly response,good dynamic performance,fast feed rate,and high positioning accuracy.   Specification:   Specifications: Vertical Machine Center VMC850l3

Model	VMC850L 3
Table size	1000*550mm
Travel (Longitude (X))	800mm
Travel (Crossward (Y))	500mm
Travel (Vertical (Z))	500mm
Distance between spindle and table	160-660mm
Distance between spindle and column	560mm
Spindle (Rotation speed)	8000/10000
Spindle (Taper)	BT40
Spindle (Motor)	7.5kw
Rapid feed (Longitude(X))	36m/min
Rapid feed (Crossward(Y))	36m/min
Rapid feed (Vertical(Z))	36m/min
Cutting feed	8m/min
Positioning accuracy	0.008mm/m
Min enactment move unit	0.001mm
Dimension(L*W*H)	2750*2535*2800mm
Net weight	5800kg
Max loaded of table	450kg

  Accessories:
