3L 5L 8L10L High quality two tower oxygen pipe /oxygen generator tube

    3L 5L 8L10L High quality two tower oxygen pipe /oxygen generator tube     Descriptions: 1. Simple structure, easy to operate, and stable oxygen output. 2. Material: zeolite/alumina; each unit can work independently, and oxygen output can reach to 3-10 LPM or higher. 3. With chiller for cooling air, no need additional refrigerant dryer for reducing cost. 4. Oxygen purity can up to 90+5%. Two oxygen cylinders exchange working, auto drain water, nitrogen and other impurities output. 5. Parts with shipping: air compressor, chiller. 6. Oxygen outlet pressure: 0.06-0.08Mpa.                            With the technology of pressure swing adsorption (PSA), OGP-OL series oxygen generator uses special molecular sieves to absorb the oxygen from the air and remove impurities output and drain water automatically.  Oxygen purity is up to 90+-3%, and oxygen outlet pressure is 0.06-0.08 Mpa. With the technology of pressure swing adsorption (PSA), OGP-OL series oxygen generator uses special molecular sieves to absorb the oxygen from the air and remove impurities output and drain water automatically.  Oxygen purity is up to 90+-3%, and oxygen outlet pressure is 0.06-0.08 Mpa.   Application: Use for industry oxygen generators in lines like:  Welding / Brazing                       Furnace Enrichment Fermentation                             Glass Industry Fish Farming                              Ozone Generator Sewage Treatment                    Pulp & Paper Chemical Oxidation                    Rough Cutting Battery Manufacture                  Melting Mini-Steel Mills                           Cement & Lime Kilns Metal Spraying                          Copper Smelting

Item	Unit	Zeolite  Material		High Efficiency Material
		OGPO3L	OGPO5L	OGPYO5L	OGPYO8L	OGPYO10L
Oxygen output	LPM	3	5	5	8	10
Oxygen concentration	%	90%±3%	90%±3%	90%±3%		93%±3%
Power	W	280	450		/	650
Pressure(inlet)	Mpa	0.18-0.2	0.2
Pressure(outlet)	Mpa	0.06-0.08
Temperature	℃	indoor temperature
Relative humidity	%	≤85%
Noise	Db	≤ 55	≤60		/	≤70
Dimension	mm	550×160×80	550×180×80	550×180×80	/	610×310×120
Weight	kg	9.25	16.70	16.74	/	19.10
