0.2MM thickness ENIG 5U'' two-sided fpcb flex pcb supplier Product capacity

Item	Description
Layer	Flex board: 1-6Layers Flex-Rigid Board: 2-8Layers
Material	PI, PET, PEN, FR-4
Final Thickness	Flex board: 0.002" - 0.1" (0.05-2.5mm) Flex-rigid board: 0.0024" - 0.16" (0.06-4.0mm)
Surface Treatment	Lead-free: ENG Gold; OSP, Immersion silver, Immersion Tin
Max / Min Board Size	Min: 0.2"x0.3" Max: 20.5"x13"
Min Trace Width / Min Clearance	Inner: 0.5oz: 4/4mil Outer: 1/3oz-0.5oz: 4/4mil 1oz: 5/5mil 1oz: 5/5mil 2oz: 5/7mil 2oz: 5/7mil
Min Hole Ring	Inner: 0.5oz: 4mil Outer: 1/3oz-0.5oz: 4mil 1oz: 5mil 1oz: 5mil 2oz: 7mil 2oz: 7mil
Copper Thickness	1/3oz - 2oz
Max / Min Insulation Thickness	2mil/0.5mil (50um/12.7um)
Min Hole Size and Tolerance	Min hole: 8mil Tolerance: PTH±3mil, NPTH±2mil
Min Slot	24mil x 35mil (0.6x0.9mm)
Solder Mask Alignment Tolerance	±3mil
Silkscreen Alignment Tolerance	±6mil
Silkscreen Line Width	5mil
Gold Plating	Nickel: 100u" - 200u"	Gold: 1u"-4u"
Immersion Nickel / Gold	Nickel: 100u" - 200u"	Gold: 1u"-5u"
Immersion Silver	Silver: 6u" - 12u"
OSP	Film: 8u" - 20u"
Test Voltage	Testing Fixture: 50-300V
Profile Tolerance of Punch	Accurate mould: ±2mil
	Ordinary mould: ±4mil
	Knife mould: ±8mil
	Hand-Cut: ±15mil

PCB or PCBA files requests. 1. Gerber files of the bare PCB board 2. BOM (Bill of material) for assembly To short the lead time, please kindly advise us if there is any acceptable components substitution. 3. Testing Guide & Test Fixtures if necessary 4. Programming files & Programming tool if necessary 5. Schematic if necessary. Our Services Pcb flexible maker,pcb soft base material,yellow soft pcb board Our Advantage: 1.Our professional engineer can provide PCB design, BOM. 2.Quick and econimic delivery term. 3.Provide PCB & PCBA prototype, and medium&low volumn quick board services. 4.Component purcharsing, SMT&PCBA one-stop source. 5.Two-hours quote response, 24 hours quick-turn produce. 6.FR4 Double-sided and Alum single-sided sample in 48 hours.
