High frequency 1000va 2000va homage inverter ups prices in pakistan

High frequency 1000va 2000va homage inverter ups prices in pakistan Specification

Model	Discription	HAX-1002	HAX-1202	HAX-2002
Capacity	VA/W	1000va/660w	1000va/800w	2000va/1440w
Battery	VDC	12VDC	12VDC	24VDC
Input	Nominal Voltage	220v/230v/240VAC
	Voltage Range	170V-280V(narrow range);90V-280V(Wide Range)
Output	Voltage	230Vac
	Voltage Regulation	188V-253V (Battery Mode)
	Frequency	50HZ or 60HZ
	Frequency Regulation	+/- 1HZ (Battery Mode)
	Output Waveform	modified sine wave
Battery & Charger	Charge Current	15Amp or 20Amp selectable		10Amp
	Overcharge Protection	16V	16V	32V
Transfer time	Typical	15ms typical,40ms max
Efficiency	AC to AC	>95%
	DC to AC	>80%
display indictor	AC mode	display output power output voltage
	Battery mode	The mark will flicker every 1 second
	Battery Charging Mode	Display battery capacity
	Fault	Display fault
Audible Alarm	Low Battery at Battery Mode	Sounding every 2 seconds
	Overload	Sounding every 0.5 seconds
	Fault	Countinuously sounding
Protection	Full Proteciton	discharge overcharge, overload, over temperature protection
Phisical	Dimension(D*W*H)	265mm*245mm*82mm
	Net Weight (KGS)	2.2	2.5	2.5
Enviroment	Operating enviroment	0-50℃,5%-90% relative humidity(non-condensing))
	Storage enviroment	-15℃ to 55℃, 5%-90% relative humidity(non-condensing)
	Noise level	less than 50dB
*Suggest the total load that you connect to is better to be less than the 80% of the unit's capacity

  Product details       Packing& Shipping

Model	Unit N.W/KGS	Unit G.W/KGS	Unit size	Unit Packing Size
HAX-1002	2.2	2.8	265mm*245mm*82mm	273mm*252mm*90mm
HAX-1202	2.5	3	265mm*245mm*82mm	273mm*252mm*90mm
HAX-2002	2.5	3	265mm*245mm*82mm	273mm*252mm*90mm
6PCS/CNT; HAX 1002 & HAX 1202 G.W 15.5KGS; HAX 2002 G.W 18.5KGS



Sample Lead Time:	7days
Packing Material:	Carton
Bulk order delivery:	20days(Specificate condition depend on quantity)

      FAQ   1. Can i buy only 1 unit?     Yes, you can buy only one unit as a sample to test performance.
2. Can you supply service of OEM, ODM?
    Yes, we can. you can print your logo on our products base on MOQ 8,000USD;
    If you want use your cover design, pls assure MOQ 1,6000 USD, and you should pay the die sinking by yourself.
    You also can choose neuutro-packing without logo.
3. Your warranty is only 12 month?     Normally, our warranty is 1 year, but you can choose to pay more 2% of good value to get 1 more year warranty.     4. if i want buy 1-3KW, but want black color, is it OK?     Yes, you can, but that must base on MOQ 8000USD.   5. Are you price compective?     Of course, we are factory price and have our own trade department.   If you want get more details, pls contact me freely!  Hot Sales   Home UPS Inverter | Off Grid Solar Inverter |  Grid Tie Solar Inverter | Battery Charger    Hybrid Inverter Grid On & Off | MPPT Solar Charger | On-line UPS| Off-line UPS| MPPT Inverter  Certificate   Company Scan   Contact Infor
