hot selling off grid solar power inverter pure sine wave inveter in 2014 Brief Introduction:
1.High transfer efficiency, highest can reach to 95%. 2.Output ture sine wave 3.Protection function completely, output short-circuit protection( take load short-circuit),Overload protection or under-voltage protectin. 4.Strong ability of resist concussion, can load all kinds of electric apparatus and industry equipments. Such as: air condition, refrigerator,television, fan, washer, fill water electric motor, tortile gate, and etc. 5.The service life is long, can reach a decade

	Model	IV7000	IV8000	IV10000	IV12000
Input	Rated capacity(W)	7000W	8000W	10000W	12000W
	Commercial Power range(VAC)	100/110/120/127/220/230(+25%,-35%)
	Frequency(Hz)	60/50±10%
Output	AVR voltage range(VAC)	100/110/120/127/220/230±10%(Auto-sensing)
	Transfer time	15ms
	Waveform	(sine)
	Frequency	60/50±0.5 Commercial power supply: shared frequency with the commercial inversion state:60/50±0.5
protection	overload	100-120%30 120%,100 150% , 150. Input/output over high or low protecting; low battery protecting; surge and pike-currents protecting; overload protecting 100%-120% 30sec; >120% 100ms; >150%, 50ms output short circuit <150ms
Battery	DC Voltage	96/192VDC
	TYPE	Sealed, maintenance-free lead acid
	Recharge current	20A(Maximum)
	Battery protection	Automatic self-test, discharge protection, over-charging protected, smart management system.
Appearance	External Size(mm) D×W×H	660280690
	Size(mm) D×W×H	760380900(1 piece)
Net weight(kg)		90	95	110	120
Gross weight(kg)		95	100	120	130
