2015 hot selling and top quality 156*156mm 60 cells AA 260W poly Solar panel

Product Description

Electrical Characteristics
Characteristics		SR156P-260
Maximum power at STC (Pmax)		260Wp
Open-Circuit Voltage(Voc)		38.5V
Optimum Operating Voltage(Vmp)		31.8V
Short-Circuit Current (Isc)		8.91A
Optimum Operating Current(Imp)		8.17A
Module Efficiency		17.10%
Solar Cell Eficiency		17.75%
Maximum System Voltage	1000V DC
Seriec Fuse Rating	16A
Power Tolerance	±1.5%



Temperature Coefficents
Temperature Coefficents
Nominal Operating Cell Temperature (NOCT)                       45±2°C
Temperature Coefficent of Pmax                           -(0.47±0.05)%/°C
Temperature Coefficent of Voc                               -(0.34±0.01)%/°C
Temperature Coefficent of Isc                               -(0.055±0.01)%/°C
WARRANTY
Manufacturing		10years
Power production		90% =12 years
80% =25 years
Mechanical Characteristics
Solar cell	Poly -crystalline 156×156mm (6inch)
No.of cells	60(6×10)
Dimensions	1640×992×40mm
Weight	20kg
Front Glass	3.2mm tempered glass
Frame	Anodized aluminium alloy
Junction Box	PV-RH701 (TUV)

  FAQ   FAQ: Q1:Are you manufacturer or trading company? We are manufacturer with factory,welcome to visit our company. Q2:Is your goods the lowest price? FOB Shenzhen price,we are cheaper than other suppliers at the same quality. Q3:Could we add ourselvess logo on product? Yes,OEM is available. Q4:How many years of your guarrantee your products? 1 year guarrantee. Company Information   Sopray solar group has two manufacturing base: Jiangsu factory & Shenzhen factory.SR Solar is the global brand we promote and a worldwide  leader in the technology,design and manufacturing,which provide innovative solar energy solution for a wide variety of customers and  applications.Existing products has been exported to Southest Asia, Europe,North America,South America,Middle East and many other  countries.And the products have passed the ISO9001,UL,CE,TUV and relevant authentication, so our quality can be best and we will try  our best to satisfied with your need.Now our annual output with mono and poly solar panel is 300MW.Besides, other products are very hot  and popular all around the world,such as solar off/on grid system,solar street lights,solar pump,solar fans and so on.We are expending our  capacity by building more factories and installing cost effective and advanced equipment to make solar energy a practical solution for more  customers around the world.We are sincerely to establish business with any customer,Our goal is:Follow the sun, and let the experts of Sopray  Solar Group to create more happy life of green environmental protection for you.
