hot selling 2014 new product 220 V solar panel solar energy

                                hot selling 2014 new product 220 V solar panel solar energy Materials of solar panel  1).Solar Cell------monocrystalline solar cell 125*125mm 2).Front Glass-------3.2mm, high transmission, low iron, tempered glss 3).EVA-------excellent anti-aging EVA 4).TPT-------TPT hot seal made of flame resistance 5).Frame------anodised aluminum profile 6).Junction Box-------lp54 rated, high quality, with diode protection Superiority: high quality anodexed aluminum frame, high efficiency long life, easy installation, strong wind resistance, strong hail resisance.   Features  1. High cell efficiency with quality silicon materials for long term output stability    2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures    3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance    4. Both Polycrystalline and Monocrystalline    5. Excellent performance in harsh weather    6. Outstanding electrical performance under high temperature and low irradiance   Quality assurance testing Thermal cycling test   Thermal shock test   Thermal/Freezing and high humidity cycling test   Electrical isolation test   Hail impact test   Mechanical, wind and twist loading test   Salt mist test   Light and water-exposure test   Moist carbon dioxide/sulphur dioxide

ITEM NO.	SR70	SR80	SR85	SR90	SR100
Material	Mono	Mono	Mono	Mono	Mono
Maximum power at STC(Pmax)	70Wp	80Wp	85Wp	90Wp	100Wp
Maximum power voltage (V)	18.00V	18.00V	18.00V	18.00V	18.00V
Maximum power current (A)	3.89A	4.44A	4.72A	5.00A	5.55A
Open-circuit voltage (Voc)	21.45V	21.85V	22.05V	22.25V	21.45V
Short-circuit current (Isc)	4.14A	4.88A	5.20A	5.38A	5.88A
Cell Efficiency (%)	13.25%	14.75%	15.65%	16.75%	18.50%
Number of cells (Pcs)	36(4*9)
Size of cell (mm)	125*125mm
Size of module (mm)	1210×540×35mm
Maximum system voltage (V)	1000V DC
Temperature coefficients of Isc (%)	-(0.055±0.01)% /°C
Temperature coefficients of Voc (%)	-(0.34±0.01)%/°C
Temperature coefficients of Pm (%)	-(0.47±0.05)%/°C
Temperature coefficients of Im (%)	+0.1
Temperature coefficients of Vm (%)	-0.38
Temperature Range	-40°C------+85°C
Surface Maximum Load Capacity	60m/s(200kg/sq.m)
Allowable Hail Load	steel ball fall down from 1m height
Weight per piece (kg)	8.5kg
Junction Box Type	PV-RH701( TUV )
Connectors and Cables Type	With TUV certificate
Length of Cables (mm)	900mm
Output tolerance (%)	-0/+3%
Frame (Material, Corners, etc.)	Aluminum
Standard Test Conditions	1000W/m2  AM1.5  25°C
Warranty	8 years product warranty and 25years 80% of power
FF (%)	≥70%
Quantity of one 20ft container	890PCS
Quantity of one 40ft HQ container	1872PCS
