high quality deep submersible water pump DC solar water pump

high quality deep submersible water pump DC solar water pump   Product Description   1) The whole DC solar water pump system consists of solar panel, controller and submersible well pump.   2) The pump is directly connected to solar panels without inverter, and the controller protects the pump, achieve high efficiency and make fullest use of solar energy.   3) The solar panel absorbs the sunlight and transfer it into DC electrical energy for the driving of submersible water pump.   4) It adopts lightning protection, water filling, permanent magnet, brushless DC, and non-sensor shielding motor, Built-in MPPT(maximum power point tracking) which can make the best use of the solar energy.       Features
1) the Max efficiency of dc solar water pump is over 85%, raise 25% than traditional AC pump.
2) High head, without noise or pollution, strong environment adaptability, greatly cost saving.   3) complete electrical protecting controller device, against Under-voltage, over-voltage, over-flow,        overload, waterless, automatic recovery, controlling water height as demand;     4) Simple structure, light weight, ,easy to installand operate and delivery.   5) maintenance-free, safe and reliable.   6) Automatic working, Operate automatically, no need caretaker, when the sun is on, it works and when       sun descends, it stops;Also you could add battery to store power for night working.   7) Environmental materials; Adopt stainless steel screw and rubber stator, permanent magnet       brushless motor.   8) Long lifespan, 25 yeas life for solar panels, 10 years for solar water pump, and 8 ye airs for       solar controller.     specification


DC 12/24V  PUMP  SERIES TECH PARAMETERS
FLOW RATE	WATER INLET		WATER OUTLET		PROTECTION CLASS		REVOLVING SPEED
3T/H	76mm		32mm		IP68		18000/rpm
FLOW RATE 3T/H      DC 12V (Voltage:12v-18v)
Model	Caryy water height		panel   (watt)		Pump Power watt	Size	Weight	Standard  wiring
123T-10	10		200		132	76*400	2.6	2M
123T-20	20		400		264	76*480	3.7	5M
123T-30	30		600		396	76*580	4.4
FLOW RATE 3T/H      DC 24V (Voltage:21v-45v)
M243T-10	10		400		192	76*400	2.1	2M
M243T-20	20		700		384	76*480	3.5	Four   square  standard    wiring      5 M
M243T-30	30		1000		576	76*560	4.5
M243T-40	40		1400		768	76*650	5.5
M243T-50	50		1800		960	76*900	6.5
M243T-60	60		2200		1152	76*1000	7.5
M243T-70	70		2600		1344	76*1100	8.5
M243T-80	80		3000		1536	76*1200	9.5
M243T-90	90		3400		1728	76*1300	10.5
M243T-100	100		3800		1920	76*1400	11.5
S483T-110	100		1000		500	76*480	12.5
D2430L-100	1.8		400		200	76*1000	7.5
C126T-4	4		300		150	76*560	4.5
C246T-4	4		400		200	76*650	5.5

    picture show
    Packaging & Shipping   1.Packaging: standard carton plus wooden case or pallet.
2.Shipping: (1). Fedex/ DHL/ TNT/ UPS for samples, door-to-door.
                  (2). By air or by sea for batch goods.
3.Delivery: Goods to be ready within 10~15 days depending on order quantity.       Our Services 1.reply clients in 24 hours.
2.Quality in priority, clients the up most.
3.Customized design is available, OEM is welcomed.
4.Delivery our goods to our customer all over the world with speed and precision.
   our factory and workshop Company Information   Along with the development of science and technology, the basic with the idea of saving energy, sopray solar group limited creat a green home for the world .our company selled solar products so many years .the main produc including :solar cell,solar panel,solar inverter ,solar controller,solar street light,solar water pump ,solar lantern ,solar off-grid system ,solar on-grid system and so on .
Existing products have been exported to southeast Asia Europe north American South America the Middle East and other countries and the area, deeply user's favorite, And the product can through the ISO9001, UL and TUV Related the authentication
our ceaseless global pursuit of the Based on the south, facing to all over the country, radiation is goal.     certification and  qualification
  FAQ
1. Are you manufacture?
Yes. We are solar water pump manufacture,welcome to visit our factory. 2. I dont know how to make selection for the solar water pump, please tell us kow to choose ?
please inform us How many m3 /hr water do you need? What is the vertical height to lift the water ? 3. How many solar panels do we need for the pump ?
you have to take concerned pump power, pump voltage, pump current requirement, we will recommend some configuration for your reference. 4.How about the warranty of solar water pump,payment?
we provide 1 year warranty for all products. Payment: T/T 30% in advance as deposit, balance the rest 70% before shipment.
5. Can I buy one as sample?
Yes, MOQ is 1 piece.       please contact with me by skype:jade0185    or    trademanager:cn1000627982
               Welcome to visit our factory and establish business with us!
