off grid hybrid solar power system hs code 2kw 3kw 5kw 10kw solar power system

off grid hybrid solar power system hs code 2kw 3kw 5kw 10kw solar power system    Materials of solar panel  1).Solar Cell------monocrystalline solar cell 125*125mm 2).Front Glass-------3.2mm, high transmission, low iron, tempered glss 3).EVA-------excellent anti-aging EVA 4).TPT-------TPT hot seal made of flame resistance 5).Frame------anodised aluminum profile 6).Junction Box-------lp54 rated, high quality, with diode protection Superiority: high quality anodexed aluminum frame, high efficiency long life, easy installation, strong wind resistance, strong hail resisance.
Breif introduction for off solar system   Optioinal working way of off grid solar systems:   1, The city power priority: when the city power is available, the inverter will work bypass out, city power will power for the load directly. Both the city power and the sun power will charge the battery. When the city power failed, just sun power will charge for the battery power for the load.   2, Battery power priority: When sun power is available, sunpower will charge the battery and power for the load, when the sunpower is not available, the battery will charge for the load. When the battery is power off,  the invnerter will automatically swicth to city power. The city power will power for the load but not charge th battery.   Detailed system calculation for 10kw off grid solar power system for your reference:   SOALR SYSTEM CONFIGURATION

PRODUCTION NAME	Solar panel	Battery	Controller	Inverter
SPECIFICATIONS	250w24v mono	12v250AH	96v100A	DC 96V  11KW
QUALITY	40	16	1	1
MAIN FEATURE
1.FOR one and a half rainy ,cloudy days
2.Systems include: solar panels, controller, inverter, stenting, cable, accumulator
3.short-circuit protection. Overload,reverse protection,
4.Sunshine condition:sunshine 11 hours a day, effectively peak sunshine 6-8 hours a day
5. environment: -15 ℃ / +65 ℃

SUPPLIER'S QUOTATION AND SPECIFICATIONS AND WARRANTY

PRODUCT DESCRIPTION	SPECIFICATIONS	QUALITY	SUPPLIER	PARAMETERS	LIFE SPAN(YEARS)	WARRANTY(YEAR)
Solar panel	24v250w mono	40	Sopray	250w :Voc=34.4V,Isc=8.29A, Vmp=31V,Imp=8.06A;	12years 90% 25years 80%	10
Controller	96v100A	1	Sopray	short-circuit protection,reverse protection,overloadSOC	10	1
Inverter	11 KW	1	Sopray	high than 90%	10	1
Battery	12v250AH	16	Sopray	maintenance-free  lead-acid batteries,  deep release 600 times.	5	1
Accessories	Accessories		structure of solar panel , cable,battery box or bracket,		20-25	1

  The HS Code of the solar panel:8541402000 and the solar power system: 850239000   *********************************************************************************************************************************************
