IEEE 1394 smt 4 pin mini usb connector

Get Latest Price

Delivery Time:: 7 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Specifications 1.Rich experience in manufacturing

2.ROHS SGS

3.100% tested before delivery

4.Free sample

5.Various types for choice

IEEE 1394 4P/F SMT TYPE SPECIFICATIONS:

Electrical
Voltage-max[volts]	5V
Current-max[amps]	0.5A
Contact Resistance[ohms]	50mΩ max.
Dielectric Withstanding Voltage	100V AC
Insulation Resistance[ohms]	100MΩ min.
Mechanical
Moting	35N max.
Withdrawal Force	10N min.
Durality	1500 cycles min.
Physical
Insulator	LCP UL94V-0
Contact	Phosphor Bronze
Mental Shell	Spcc
Copper Flake	Capper Alloy
Plating	Gold Flash/Gold 30um
Temperature Range	-25°C to +85°C

Engineering drawing:

Our Advantages: 1.All kinds of our products have passed ROHS. 2.Our factory has passed the ISO9001:2000 certification and ISO1400 Certification. 3.We mainly produce the connectors which are used on the Internet,storage,digital computer and other related products. 4.We are glad to make samples according to your drawings and specifications. 5.Available for ODM/OEM order. 6.Please contact us so we can offer you the best quality,competitive price and timely delivery.
