2.54mm IDC connector grey color with strain relief

Specifications 1.ISO9001:2008/ISO14001:2004

2.Experienced manufacturer

3.Specification is customized

4.Various types for choice

5.ROHS/SG

2.54mm IDC Socket   1.Specification:   Current      rating     :3AMP
Operation    temperature:-40 to 105°c
Contact      resistance :20mΩ max
Insulation   resistance :1000mΩ min
Withstanding voltage    :AC1000V
Insulator    material   :Polyster (UL94V-0)/Standard:PBT
Contact      material   :Brass   Contact       plating    :AU or Sn  over 50 u'' Ni   2.Engineering Drawing:       3.Our Products   4.Order Information   (1) Pitch series: 2.54*2.54;2.0*2.0,1.27*2.54mm   (2) Number of contacts: 02-80pin   (3) Contact plated: Tin/ gold flash /gold 3U"/ gold 5U"/ gold 10U"/ gold 15U"/ gold 30U"    (4)Material type: PPS/ PBT/  LCP/ Nylon-66/ Nylon-6T/ PA46    (5)color: black/grey   (6).Contact Plated: Tin / Gold Flash / Gold 3u''/ Gold 5u''/ Gold 10u''/Gold 15u" / Gold 30u''   (7)Material Type: PPS / PBT / LCP / Nylon-66 / Nylon-6T / PA46  Advantagement 1.All kinds of products passed ROHS,SGS, 100% tested before delivery.   2.Factory passed ISO9001:2008 and ISO14001:2004.   3.Available for ODM/OEM order.   4.Some plasitic have passed UL certificated.    5.Well-equipped testing facilities and strong technical force   6. Prompt delivery and competitive price and quality   7. Used in the most of home appliances,computer,PCB,LCD,TV
