CE Custom 3G Programmable LED Display / Digital Full Color Pixel Pitch
Quick Viewing:
1. Color temperature 3200-9300 k adjustable;
2. FCC/CE/TUV/ETL/RoHS certificated, both Europe and North America are satisfied;
3. It has a long lifetime of 100000 hours;
4. It can work under -40F–140F (-40-60℃) /5%-95%RH(non-condensing);
5. DC9-36V large scale of input voltage, typical value: DC12V/24V;
6. Horizontal and vertical 120 degree Plus larger viewing angle than taxi LCD screens;
7. Supporting text, graphics, video or flash, more choice than traditional taxi top backlit advertising, this needs printing and only showing one advertisemetn one time.
Detailed Description:
Powerful control software:
Outdoor Taxi Roof Video LED full color display had a powerful software and WiFi .User- friendly software interface, user were able to enter into the WEB version, upload and update the contents, and it would also check the statement of the contents and playing under the Functions of asynchronization control.
Vivid illustrations, rich contents:
Supports kinds of information including flash, picture, video and text, in the meantime to meet the demand of commercial advertising communication, display forecasting, early warning, headline news message which is vitally related to city life, thus enhances the audience's dependence on the media, and keep the media vitality.
Visibility in all conditions:
Larger viewing angle Horizontal 120 degree, vertical 120 degree. Original and vivid display effect will be seen in this scope with color excursion free and image distortion free. 465cd/sq.ft (5000cd/㎡) brightness can be installed in different environment.
Well Designed Cooling System:
Outdoor taxi roof video led full color display has special cooling system design. The air goes inside from the heading direction and soon form the air flow inside the display as below illustration shows and two fans at the back-end of the display will pull the air which will make the equipment work more reliable in high temperature and high humidity environments.
Popular Application:
Digital taxi led display media, Mobile taxi led display advertising
Specifications:
Item | Technical Parameters | |
Screen model | OC-MT-P5SMD2525 | |
R chip (wavelength range: 620-630nm, 5nm) | Brightness range: 500-900mcd | |
G chip (wavelength range: 460-470nm, 4nm) | Brightness range: 1200-1500mcd | |
B chip (Wavelength range: 520-530nm, 4nm) | Brightness range: 300-450mcd | |
Module | Led configuration | SMD 3 IN 1: SMD2525/SMD3528 |
Pixel pitch (mm) | 5mm(0.2 inch) | |
Module resolution (W X H) | W 32 x H 32 dots | |
Module dimension(W x H inch) | W 6.3 x H 6.3 x D 0.67 inch | |
Cabinet | Module quantity(W × H) | W 6 × H 2, per side |
Cabinet resolution(W × H) | W 192 × 64 dots, per side | |
Cabinet dimension(W x H inch) | W 37.80 x H 12.60 inch per side | |
Cabinet surface area(sq.ft) | 3.31 sq.ft / (0.31sq.m) per side | |
Physical pixel density(dots/sq.ft) | 3716dots/sq.ft(40000dots/㎡) | |
Brightness | ≥465CD/sq.ft (5000CD/㎡) | |
Cabinet flatness(inch) | ≤0.08inch (0.2mm) | |
Maintenance | Back-maintained | |
Cabinet material | Aluminum | |
Cabinet weight | ≤48.5lb (22kg) | |
Optical parameters | Single-point brightness correction | available |
Single-point color correction | available | |
Color temperature(K) | 3200—9300 adjustable | |
Horizontal viewing angle | 120° | |
Viewing angle (Vertical) | 120° | |
Brightness Uniformity | <3% | |
Color uniformity | ≥97% | |
Contrast ratio | 5000:1 | |
Electrical parameters | Max power consumption | 580W per unit of taxi led screen |
Average power consumption | 180-240W per unit of taxi screen | |
Power supply | DC9-36V | |
Security Features | GB4943/EN60950 | |
Drive mode | Constant Current Driver, 1/8 scan | |
Gray scale level | 10 bit | |
Refresh rate(Hz) | ≥960 | |
Processing | ≥14 bit | |
Module comes with power failure | Save luminance, Color correction, module data | |
Use parameter | Life time(hrs) | 100,000 hours |
Operating temperature / humidity | -40F–140F (-40-60℃) /5%-95%RH(non-condensing) | |
Storage temperature / humidity | -40F–140F (-40-60℃) /5%-95%RH(non-condensing) | |
Certification | CCC/FCC/TUV/CE/ETL | |
