4Ch Passive Video Balun
-
$4.001-0 Piece/Pieces
-
$4.50≥1 Piece/Pieces
- Transportation:
- Ocean, Land, Air
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Productivity: | 2000pcs/month |
| Supply Ability: | 2000pcs/month |
| Payment Type: | T/T |
| Transportation: | Ocean,Land,Air |
Product Description
Product Description
Feature:
* 4 Channel Passive Video Transceiver
* 60 dB crosstalk and noise immunity
* Outstanding interference rejection
* Quality color and B&W video signals over 1000 feet (330 m) of unshielded twisted pair wires, with active UTP receiver can transport quality video up to 4,500 feet
* Compatible with all qualified UTP cameras
Specification:
|
Frequency Range
|
DC--8MHz
|
|
Material
|
Metal
|
|
Impedance
|
Twisted Pair 100ohms ; Coax 75ohms
|
|
CMRR/Attenuation
|
60dB/0.3dB type
|
|
Transmission distance
|
About 600M(W/B Video); About 400M(Color Video)
|
|
Power output
|
Constant DC12V 0.75A
|
|
Interface
|
UTP RJ45; 4*BNC (Male) Connector
|
|
Impedance
|
BNC-75ohms, Terminal-100ohms
|
|
Suppression
|
6000V 10uS*700uS IEC61000-4-5
|
|
Wire Type
|
24-16AWG UTP CAT5 or higher;Loop DCR<18ohms/100m
|
|
Working Temperature
|
-20℃ ~ +70℃
|
|
Storage Temperature
|
-30℃ ~ +70℃
|
|
Humidity
|
0 ~ 95%
|
|
Weight(Net)
|
60g/pcs
|
Package contains:
Video Balun×1Pcs
