SMD Full Color Indoor LED Display for Wedding / Exhibition
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Shenzhen China |
|---|
SMD Full Color Indoor LED Display for Wedding / Exhibition , Stage LED Display Rental
Description
1. Higher cost performance.
2. Lower maintenance cost .
3. Combined with the control system which has more than 14bit processing ,effecting a higher gray level. 4. Red,green and blue LED chips incorporated encapsulation ,better perspective. Strong adaption to environment.
specifications
1.Indoor led Display technical parameter
|
Pixel Density(pixel/㎡) |
65356 |
|
White Balance Brightness (cd/㎡) |
≥1200(adjustable) |
|
Max Power Consumption |
200W/cabinet |
|
Average Power Consumption |
100W/cabinet |
|
Color Temperature |
3200-9300(adjustable) |
|
View Angle |
Horizontal 110°;Vertical 110° |
|
Best Viewing Distance(m) |
4m—100m |
|
Display Work Method |
1/16 scan |
|
Digital Processing |
14 bit |
|
Gray Scale |
65536 levels per color |
|
Refresh Frequency (Hz) |
≥800 |
|
Input Signal |
Video: PAL/NTSC Option: VGA , Video , DVD,TV, SDI.HDMI etc |
|
Waterproof |
No |
|
Working Temperature(ºC) |
-20~+45 |
|
Humidity(RH) |
10% - 80% |
|
Stored Temperature (ºC) |
-30~+60 |
|
Lifetime (50%Brightness)(Hours) |
≥100,000 |
|
Input Voltage(VAC) |
AC 220(or 110V) |
|
Input Power Frequency(Hertz) |
50 to 60 |
|
Data Connection |
Super CAT6 Cable or Fiber |
|
Operating System |
Windows(98/2000/XP/Vista) |
|
Blind Spot Rate |
＜0.00001 |
|
Control Distance |
CAT6 cable:150 meters; Single Fiber: Up To 10 Kilometers |
|
Panel Input Format (With Video Processor) |
VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV |
|
Earth Leakage Current(mA) |
＜2 |
|
Pixel Configuration |
SMD2121 |
Pixel Pitch | 3.91mm |
| Module Resolution |
64x64 |
Module Size(W*H) |
250mm x 250mm |
|
Weigth Per Module |
0.58kg |
Max Power Consumption |
45w |
3. Indoor LED Display Cabinet
|
Cabinet Size(W*H) |
500mm × 500mm |
Module Qty |
4 pcs |
|
Cabinet Resolution |
128 x 128 |
Cabinet Area |
0.25㎡ |
|
Weight Of One Cabinet |
8.5 kg |
Cabinet Pixel |
65536 |
|
Cabinet Flatness |
＜0.2/㎡ |
Cabinet Material |
Die Casting Cabinet |
Applications
This Indoor Full Color LED Display Are Very Popular In Commercial Advertising Field . such as Community, bus station, schools, telecommunications, customs, stadiums, studio,shopping malls, airports, etc;
competitive advantage
1. Good Sevice , 24/7 online support service.
2. Good Quality For Every LED Display Product.
3. Good Price.
4. High Quality Driving IC .
5. Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.
6. Two Years Maintenance Service With Free.
