Wimax Indoor CPE
- Payment Type:
- T/T, Western Union
- Incoterm:
- FOB
- Min. Order:
- 100 Piece/Pieces
- Min. Order:
- 100 Piece/Pieces
- Delivery Time:
- 50 Days
- Transportation:
- Ocean, Air
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | shenzhen |
|---|---|
| Productivity: | 100000pcs/week |
| Supply Ability: | 1000000pcs/year |
| Payment Type: | T/T,Western Union |
| Incoterm: | FOB |
| Certificate: | ce |
| Transportation: | Ocean,Air |
Product Description
Product Description
Product Highlights
Sophisticated data and voice QoS control
Best-in-class radio performance with high gain directional antenna and MIMO support
Standard based security and quality of services classes support
FEATURE HIGHLIGHTS
Cost effective & compact design with built-in high gain LTE and WiFi antenna;
Full compliance to 3GPP2 LTE Release 9 specifications;
Advanced MIMO support and Category 4 throughput;
Dual LAN ports, SIP 2.0 VoIP and 802.11b/g/n MIMO WiFi support;
Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support;
FTP, HTTP and TR-069 management support;
SIM card authentication and virtual SIM support.
RELIABLE & CONVENIENT WIRELESS BROADBAND ACCESS
Jaton 3000W is a highly advanced mobile WiMAX home gateway specifically designed to meet integrated data and Wi-Fi access needs for residential, business and enterprise users. It integrates the function of WiMAX data router and WLAN AP. It can provide high data throughput and advanced networking features to customers who needs both bandwidth and Wi-Fi connectivity.
RELIABLE PERFORMANCE
3000W is a cost effective and reliable indoor CPE product based on the WiMAX Forum's standard implementation of the IEEE 802.16e Wave II specification. It can meet the most demanding requirements of major service providers with high data throughput and availability. It also supports standard OMA-DM and TR069 management interface for centralized auto provision and upgrade management. Network operators can count on the performance and reliability of the device to provide mass service deployment.
Equipped with four 10/100Mbps Ethernet data ports and high performance 802.11 b/g/n Wi-Fi AP module, the device provides an effective all-in-one solution to the home networking user. Factors such as integrated antenna design, increased power efficiency and high antenna gain also improve the operational life span of the device.
3000W provides unified access for multimedia broadband data and Wi-Fi simultaneously. It supports VPN pass through and all the services defined by the WiMAX forum to ensure greater service feasibility and reliability. Easy-to-read signal strength and data activity LED indicators in the front of the device make it intuitive for users to check the status of the device.
CONVENIENT USAGE AND MANAGEMENT
3000W is a user-friendly WiMAX CPE, and very convenient for both using and managing. Easy and simple, self installation for non professional user delivers instant broadband anywhere. All interfaces in the plug and play irStream 3000W are fully integrated and it comes with all the necessary device drivers pre-loaded. Subscribers just connect the device to their LAN computer and the device is ready to offer an experience of surfing over Internet. The LEDs on the Jatontec 3000W have also been designed for user convenience, and offer a clear sign of what the device is doing. The compact design is well suited for residential home use. The IP addresses can be statically allocated or dynamically obtained via DHCP.
3000W offers rich management features which facilitate the task of service provider. It supports management by Telnet, WEB, and standard based OMA-DM and TR-069 solution for centralized device configuration, upgrades and monitoring. To meet challenges of service deployment in different countries and regions, Jatontec 3000W is designed to operate over a wide frequency spectrum in 2.3-2.4GHz (F23), 2.5-2.7GHz (F25) and 3.3-3.7GHz (F35) bands, which gives much greater flexibility in frequency planning for the service provider and ease of roaming for the end customer.
TECHNICAL FEATURES
3000W supports for 2x2 MIMO, adaptive modulation and coding (AMC) technology to maximize the system capacity and bandwidth throughput by automatically adjusting modulation to respond to various signal qualities. With the built-in high gain Omni Directional antenna, Jatontec 3000W enables a longer reception range from the base station. This yields more efficient use of the network with a larger cell reach, guaranteed carrier class service, and customer service probability. Advanced Orthogonal Frequency Division Multiplexing (OFDM) modulation enhances performance in non-line-of-sight (NLOS) conditions to ensure immunity to interference and multi-path conflicts typical of deployments in densely populated urban areas. Moreover, sophisticated QoS capabilities in the 802.16e MAC, 802.1P and DSCP classification and prioritization functions ensure true end-to-end QoS and support high quality data, voice and video services. Its unique single BB+RF processor product architecture allows the lowest possible cost of ownership. Simple installation procedure further reduces the product deployment and support cost for service providers.
Sophisticated data and voice QoS control
Best-in-class radio performance with high gain directional antenna and MIMO support
Standard based security and quality of services classes support
FEATURE HIGHLIGHTS
Cost effective & compact design with built-in high gain LTE and WiFi antenna;
Full compliance to 3GPP2 LTE Release 9 specifications;
Advanced MIMO support and Category 4 throughput;
Dual LAN ports, SIP 2.0 VoIP and 802.11b/g/n MIMO WiFi support;
Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support;
FTP, HTTP and TR-069 management support;
SIM card authentication and virtual SIM support.
RELIABLE & CONVENIENT WIRELESS BROADBAND ACCESS
Jaton 3000W is a highly advanced mobile WiMAX home gateway specifically designed to meet integrated data and Wi-Fi access needs for residential, business and enterprise users. It integrates the function of WiMAX data router and WLAN AP. It can provide high data throughput and advanced networking features to customers who needs both bandwidth and Wi-Fi connectivity.
RELIABLE PERFORMANCE
3000W is a cost effective and reliable indoor CPE product based on the WiMAX Forum's standard implementation of the IEEE 802.16e Wave II specification. It can meet the most demanding requirements of major service providers with high data throughput and availability. It also supports standard OMA-DM and TR069 management interface for centralized auto provision and upgrade management. Network operators can count on the performance and reliability of the device to provide mass service deployment.
Equipped with four 10/100Mbps Ethernet data ports and high performance 802.11 b/g/n Wi-Fi AP module, the device provides an effective all-in-one solution to the home networking user. Factors such as integrated antenna design, increased power efficiency and high antenna gain also improve the operational life span of the device.
3000W provides unified access for multimedia broadband data and Wi-Fi simultaneously. It supports VPN pass through and all the services defined by the WiMAX forum to ensure greater service feasibility and reliability. Easy-to-read signal strength and data activity LED indicators in the front of the device make it intuitive for users to check the status of the device.
CONVENIENT USAGE AND MANAGEMENT
3000W is a user-friendly WiMAX CPE, and very convenient for both using and managing. Easy and simple, self installation for non professional user delivers instant broadband anywhere. All interfaces in the plug and play irStream 3000W are fully integrated and it comes with all the necessary device drivers pre-loaded. Subscribers just connect the device to their LAN computer and the device is ready to offer an experience of surfing over Internet. The LEDs on the Jatontec 3000W have also been designed for user convenience, and offer a clear sign of what the device is doing. The compact design is well suited for residential home use. The IP addresses can be statically allocated or dynamically obtained via DHCP.
3000W offers rich management features which facilitate the task of service provider. It supports management by Telnet, WEB, and standard based OMA-DM and TR-069 solution for centralized device configuration, upgrades and monitoring. To meet challenges of service deployment in different countries and regions, Jatontec 3000W is designed to operate over a wide frequency spectrum in 2.3-2.4GHz (F23), 2.5-2.7GHz (F25) and 3.3-3.7GHz (F35) bands, which gives much greater flexibility in frequency planning for the service provider and ease of roaming for the end customer.
TECHNICAL FEATURES
3000W supports for 2x2 MIMO, adaptive modulation and coding (AMC) technology to maximize the system capacity and bandwidth throughput by automatically adjusting modulation to respond to various signal qualities. With the built-in high gain Omni Directional antenna, Jatontec 3000W enables a longer reception range from the base station. This yields more efficient use of the network with a larger cell reach, guaranteed carrier class service, and customer service probability. Advanced Orthogonal Frequency Division Multiplexing (OFDM) modulation enhances performance in non-line-of-sight (NLOS) conditions to ensure immunity to interference and multi-path conflicts typical of deployments in densely populated urban areas. Moreover, sophisticated QoS capabilities in the 802.16e MAC, 802.1P and DSCP classification and prioritization functions ensure true end-to-end QoS and support high quality data, voice and video services. Its unique single BB+RF processor product architecture allows the lowest possible cost of ownership. Simple installation procedure further reduces the product deployment and support cost for service providers.
