RF Transceiver COB Module
- Payment Type:
- T/T, L/C, Western Union, paypal
- Incoterm:
- FOB
- Min. Order:
- 1000 Piece/Pieces
- Min. Order:
- 1000 Piece/Pieces
- Delivery Time:
- 7 Days
- Transportation:
- Ocean, Land, Air
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Jiangsu\Nanjing\Shenzhen China |
|---|---|
| Productivity: | 1000000O00PCS/Year |
| Supply Ability: | 1000000PCS/month |
| Payment Type: | T/T,L/C,Western Union,paypal |
| Incoterm: | FOB |
| Certificate: | RoHS\ESD\FCC\ETSI\REACH\Reliability Report |
| Transportation: | Ocean,Land,Air |
Product Description
Product Description
HOPERF has developed into the domestically first intact industry chain group company integrating ASIC chip design, MEMS sensor chip design, package test calibration technique and application services. HOPERF owns a top R & D design team with more than 80 persons globally and it has 16 years' experience in the industry, covered 33 countries and served for 1073 brand customers globally.
RF Advantages:
LoRa spread spectrum modulation technology, enabling long communication distance and very strong interference immunity
Link budget greater than 157dB, mainstream applications, cost-effective
Small highly integrated module design, facilitating the design of the target product
Application:
AMR Auto Meter Reading, Industrial Control System, Wireless Remote Control Equipment, Mining Safety Monitoring, Extremely Long-Distance Data Communications, Field Data Remote Control, Building Automation, Security, Garage\Underground\Tunnel Monitoring Equipment, etc.
Parameter:
Frequency: 868/915MHz
Modulation Mode: LoRa/FSK/GFSK/OOK
Output Power: 20dBm
Sensitivity: -136dBm (LoRa, BW=125kHz, SF=12, CR=4/5, 1%PER)
Data Rate: FSK: 300Kbps; OOK: 32Kbps;
Tx Current: 125mA (+20dBm)
Rx Current: 10.5mA
Standby Current: 0.1μA
Interface: SPI
Communication Distance: > 8000m(1.2kbps)@LoRa
Antenna Impedance: 50Ω
Operation Temperature: -20~+70
Power Supply Mode: DC 1.8~3.7V, 1.8V Transmission power
Of power supply will not fall
Module Size: 16X16mm
Certifications:
FCC\ETSI\RoHS
RF Advantages:
LoRa spread spectrum modulation technology, enabling long communication distance and very strong interference immunity
Link budget greater than 157dB, mainstream applications, cost-effective
Small highly integrated module design, facilitating the design of the target product
Application:
AMR Auto Meter Reading, Industrial Control System, Wireless Remote Control Equipment, Mining Safety Monitoring, Extremely Long-Distance Data Communications, Field Data Remote Control, Building Automation, Security, Garage\Underground\Tunnel Monitoring Equipment, etc.
Parameter:
Frequency: 868/915MHz
Modulation Mode: LoRa/FSK/GFSK/OOK
Output Power: 20dBm
Sensitivity: -136dBm (LoRa, BW=125kHz, SF=12, CR=4/5, 1%PER)
Data Rate: FSK: 300Kbps; OOK: 32Kbps;
Tx Current: 125mA (+20dBm)
Rx Current: 10.5mA
Standby Current: 0.1μA
Interface: SPI
Communication Distance: > 8000m(1.2kbps)@LoRa
Antenna Impedance: 50Ω
Operation Temperature: -20~+70
Power Supply Mode: DC 1.8~3.7V, 1.8V Transmission power
Of power supply will not fall
Module Size: 16X16mm
Certifications:
FCC\ETSI\RoHS
