P6 p5.33,576*576 die casting aluminum cabinet rental LED display,P6 Indoor Rental Led Display Die Cast Aluminum Cabinet

P6 p5.33,576*576 die casting aluminum cabinet rental LED display,P6 Indoor Rental Led Display Die Cast Aluminum Cabinet

USD1

≥5 Square Meter

Payment Type:: T/T

Incoterm:: FOB

Min. Order:: 5 Square Meter

Min. Order:: 5 Square Meter

Delivery Time:: 7 Days

Transportation:: Ocean, Land, Air

Port:: SHENZHEN, SHEKOU, HK

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	10000/month
Supply Ability:	10000/month
Payment Type:	T/T
Incoterm:	FOB
Certificate:	ISO CE UL ROHS FCC CCC EMC
Transportation:	Ocean,Land,Air
Port:	SHENZHEN,SHEKOU,HK

Product Description

P6 576*576 die casting aluminum cabinet rental LED display,P6 Indoor Rental Led Display Die Cast Aluminum Cabinet 576*576mm

Arise Technology Co., Ltd. One-stop LED display manufacturere

Arise Technology Co., Ltd. One-stop LED display manufacturere
info[at]ariseled[dot]com
[www][at]ariseled[dot]com

Features:

1.P6 rental led display with SMD surface- mount triple packing technology, 140 ° ultra-wide viewing angle,large range of audience;

2.High brightness, high contrast, wide Gamut, high refresh rate, direct sunlight viewable, good display effect

3.Equipped with intelligent light sensing device, the environment adaptive adjustment does not affect the display of energy-saving and environmentally friendly.

4.Available direction, any size, any shape stitching, presenting a seamless visual effects;

5.P6 rental led display with die-casting aluminum frame design, ultra-light, ultra-thin, space-saving, costs-saving and fashion style;

6.Adopting die-casting aluminum improves the heat dispersion, prolonging the lifetime of the led display.

7.High reliability, long lifetime and low maintenance costs;

8.After cabinet open the door design, module front or rear maintenance ;

9.High weatherability, IP65 protection grade, suitable for outdoor products.

10.High brightness, high contrast, wide color gamut, high gray-scale and refresh, the sun shoots directly still making the picture clear and bright, display effect natural and real.

20121120170613

Pitch/mm	p5.33	p6
Module size/mm	288x288	288x288
Density of pixel/(dots/m2)	35,200	27,777
Pixel composition	1R1G1B	1R1G1B
Led encapsulation	SMD3528	SMD3528
Resolution of module	54X54	48X48
Optimum viewing distance	5-16m	7.5-20m
View angle / °	140H,120V	140H,120V
Max power consumption/W/M2	1,000	1,000
Size of cabinet/mm	576x576	576x576
Resolution of cabinet	108X108	96x96
Weight of cabinet/kg	8	8
Driving method	1/9 scan constant current	1/8 scan constant current
Refresh rate Hz/S	≥1500	≥1500
Luminance of white balance	≥1500 nits	≥1500 nits
Operation of Environmental Temperature/°C	below 30 to above 50
Working vlotage	110-220 VAC/+/- 10%
Grey scale/color	displaying colors≥16.7M(synchronized)
Brightness adjustment	256 levels of each color(manually),100 levels of each color(automatically)
Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system	linsn(sending card,receiving cards and Hubs)
Average of non-failure life	>50,00h
Life span	>100,000h
Defect dot rate	<0.0001

Strict Aging Test

All products undergo a strict aging test. The 72 hours aging test is conducted without die lamp, dim lamp, color difference and mosaic. The product is introduced in the market only if it passes the aging test, making sure the best quality is ensured for you.

Application

The Outdoor LED Video Wall is highly usable at outdoor places like malls,stages, promotion, exhibitions, stations, stadiums stages, promotion, exhibitions, stations, stadiums stages, promotion, exhibitions, stations, stadiums, etc. Its thin size and ultra-lightweight module makes it easy to install at any area without covering much space.

20110208113442308

This is our LED display category from Arise Technology Co., Ltd. Thanks for your attention.

Category	Pixel Pitch(mm)
1. Outdoor Fix Installation LED Display Series	P4/ P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16
2. Outdoor Strip/Louver LED Display Series	P15.625-15.625/ P15.625-31.25/ P31.25-31.25
3. Outdoor Rental LED display Series	P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10
4. Indoor Fix Installation LED display Series	P1.2/P1.56/P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/
	P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
5. Indoor Rental LED Display Series	P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/
	P6.25/ P6.4/ P7.62/ P8/ P10
6. Transparent LED Display Series	P3.9-7.8/ P7.8-15.625/ P8/ P10
7. Floor LED Display Series	P6.25/ P6.25 interactive floor LED display /P8.9/ P10.4
8. Perimeter LED Display Series	P6/ P8/ P10/ P12/ P16
9. LED Advertising Player/Kiosk LED Display Series	P2.5/ P3/ P4/ P5/ P5.3/ P6
10. Taxi/Bus Mounted LED Display Series	P4/ P5/ P6/ P7.62
11. LED Ball Display Series	P3/ P4/ P5/ P6/ P7.62/ P8/ P10
12. Multiple creative LED displays and DJ booth LED displays for clubs and stages.
