Sport stadium LED dsiplay 1280×1024mm Pixel pitch p8mm p10mm,ARISELED.COM

Sport stadium LED dsiplay 1280×1024mm Pixel pitch p8mm p10mm,ARISELED.COM

Get Latest Price

Payment Type:: T/T

Incoterm:: FOB

Min. Order:: 5 Square Meter

Min. Order:: 5 Square Meter

Delivery Time:: 7 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Shekou, HK

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	10000/month
Supply Ability:	10000/month
Payment Type:	T/T
Incoterm:	FOB
Certificate:	ISO CE UL
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Shekou,HK

Product Description

Sport stadium LED dsiplay 1280×1024mm Pixel pitch p8mm p10mm,ARISELED.COM

Arise Technology Co., Ltd. One-stop LED display manufacturere

info[at]ariseled[dot]com
[www][at]ariseled[dot]com

Features:

1.Angle:60° 65° 70° 75° 80° 85° 90°;

2.IP65 rating, our cabinets offer ventilation and protection from rain or water damage;

3.Perimeter LED display could provide pixel resolution of P10, P12 P16 P20;

4.Our stadium perimeter screen can be taken Front Service design

Pixel Pitch	8 mm	10 mm
Cabinet size	1280X1024X160mm	1280 x 960 x 160mm
Resolution	15625 pixel/㎡	10000 pixel/㎡
Pixel Configuration	SMD 1R1G1B	SMD 1R1G1B
Brightness	≥6500cd/㎡	≥5600cd/㎡
Grey Scale	14 bit	14 bit
Scanning Mode	1/4	1/4
Refresh Rate	≥2880Hz	≥2880Hz
Max Power	800 W/cabinet	700 W/cabinet
Average Power	230 W/cabinet	180 W/cabinet
Weight	51.5 kg/cabinet	48 kg/cabinet
Ingress Protection	IP65	IP65
Module Size	256X128X22	320X160X22
Power Supply	90VAC~264VAC 50/60Hz
Visual Angle	120°/120°(H/V)
color temperature	6500 (3200-9300K adjustable)
Life span	10000h
Working temperature	-20℃ to+40℃
Working humidity	20% to 90%
Stored temperature	-40℃ to +60℃
Stored humidity	10% to 95%

Packaging & Shipping

1.We can offer any kinds of the standard & customized package for you/ such as: Flight case/ wooden case & paper carton. We can also help you print your logo on your package case & also the product itself.

2.We Provide Drop shipping Service. In order to ensure you receive your order tax free upon import/ we declare lower value.

3. For Regular standard cabinet orders/ we can ship out in 1-2 working days after receiving your sample confirmation and payment; for big customized OEM Order: we need longer time/ around 15-25 working days after receiving your sample confirmation.

After-sale service

1. Lifetime free maintenance and upgrade.

2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

3. Customer satisfaction tracking report.

4. Free technician training.

5. Full set of documents free of charge/ which including installation guidance/ software operation manual/ easy maintenance manual and control system software CD and so on.

Warranty:

1.We will provide a sum of spare parts to you together with the shipment(the details are as above)/ it included like leds/ power supply/ modules/ cables-and so on/ and it`s enough for the replacement within 2 years.

2.We will provide two years warranty for our products. That means two years of factory labor and components is provided for free/ however the customer should pay for the round shipping cost for broken parts.

3. For the technical support/ we will send the installation drawings/ user manual after the order is confirmed/ and we can offer the free training for your technician in our factory until he can manage it well.

4. For the installation/ if you need/ we can send an engineer to your country to help & instruct the installation/ but your side need to pay for the round tickets and accommodation.

5. For future service/ if you meet any problems/ our overseas engineer will service you online or by phone in 7x24 hours.

QQ20160512095341

This is our LED display category from Arise Technology Co., Ltd. Thanks for your attention.

Category	Pixel Pitch(mm)
1. Outdoor Fix Installation LED Display Series	P4/ P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16
2. Outdoor Strip/Louver LED Display Series	P15.625-15.625/ P15.625-31.25/ P31.25-31.25
3. Outdoor Rental LED display Series	P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10
4. Indoor Fix Installation LED display Series	P1.2/P1.56/P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/
	P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
5. Indoor Rental LED Display Series	P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/
	P6.25/ P6.4/ P7.62/ P8/ P10
6. Transparent LED Display Series	P3.9-7.8/ P7.8-15.625/ P8/ P10
7. Floor LED Display Series	P6.25/ P6.25 interactive floor LED display /P8.9/ P10.4
8. Perimeter LED Display Series	P6/ P8/ P10/ P12/ P16
9. LED Advertising Player/Kiosk LED Display Series	P2.5/ P3/ P4/ P5/ P5.3/ P6
10. Taxi/Bus Mounted LED Display Series	P4/ P5/ P6/ P7.62
11. LED Ball Display Series	P3/ P4/ P5/ P6/ P7.62/ P8/ P10
12. Multiple creative LED displays and DJ booth LED displays for clubs and stages.

Arise Technology Co., Ltd. One-stop LED display manufacturere

info[at]ariseled[dot]com
[www][at]ariseled[dot]com
