flat Fiber Ribbon cable
- Payment Type:
- T/T
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 3 Days
- Transportation:
- Ocean, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Payment Type: | T/T |
| Certificate: | ROHS |
| Transportation: | Ocean,Air |
Ribbon fiber flat cable use fiber ribbon as optical communication medium, the fiber ribbon wrapped with a layer of aramid yarn as strength member units, and the cable is completed with a flat PVC or LSZH jacket.
Standards
Comply with standard GR-409, IEC 60794-2-30/31, meet the requirements of UL approval for OFNR.
Characteristics
Ø Aramid yarn as strength member cable has excellent tensile strength.
Ø Compact structure with high fiber density, good performance of flexibility and crush resistance
Ø The jacket anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to environment
Ø All dielectric structure design, without electromagnetic induction effect
Ø Scientific design with serious processing art.
Specification
|
Fiber Type |
G652D,G657A1,G657A2,OM1,OM2,OM3,OM4 |
||||
|
Fiber count |
4 |
6 |
8 |
12 |
|
|
OD(D*H(mm)±0.3mm) |
3.5*2.5 |
3.8*2.5 |
4.5*2.5 |
5.0*2.5 |
|
|
Max. tensile Strength (N) |
Short-term |
150 |
|||
|
Long-term |
80 |
||||
|
Min. Bending Radius (mm) |
Dynamic |
60 |
|||
|
Static |
30 |
||||
|
Min/Max.Crush Resistance (N/100mm2) |
200/1000 |
||||
|
Temperature range |
PVC: -20°C ~+90°C ;LSZH:-20°C ~+70°C |
||||
