Printing method | Direct Thermal / Thermal Transfer | |
| | Printing resolution | 203 dpi (8 dots/mm) | |
| | Printing Speed | 2~ 3 ips (51~76mm/s) | |
| | Printing Length | Max 43”(1092mm) | |
| | Printing Width | Max 4.16”(105mm) | |
| | Memory | 8MB DRAM(7MB user available)
4MB Flash ROM(3MB user available) | |
| | CPU Type | 32 bit RISC microprocessor | |
| | Sensors | Reflective | |
| | Operation Interface | LED indicator (Power/Ready)x 2, Button(Feed) x 1 | |
| | Communication Interface | Centronics Parallel,
RS-232, USB | |
| | Fonts | Internal character sets standard
5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm)
Internal fonts are expandable up to 24x24
4 direction 0 ~ 270 rotation
Soft fonts are downloadable | |
| | 1D Barcodes | PPLA: Code 39, Code 93,Code 128/subset A/B/C, Codabar, Interleaved 2 of 5, UPC A/E/2/5 add-on, EAN-13/8, UCC/EAN 128, Postnet, Plessey, Interleaved 2 of 5, Interleaved 2 of 5 with a modulo 10 checksum, Interleaved 2 of 5 with a modulo 10 checksum and shipping bearer bars , Code 128, UCC/EAN Code 128 Random Weight, HBIC, Telepen , FIM
PPLB: Code 39, Code 93, Code 128/ subset A,B,C, Codabar, Interleaved 2 of 5, Interleaved 2 of 5 with check sum digit, Interleaved 2 of 5 with human readable check digit, Matrix 2 of 5, UPC A/E 2 and 5 add-on, EAN-8/13, Code 128UCC, UCC/EAN, Postnet | |
| | 2D Barcodes | PPLA: PDF-417, MaxiCode, Data Matrix (ECC200 only) ,QR Code, Composite codes
PPLB: MaxiCode, PDF-417, QR Code, Composite codes | |
| | Graphics | PPLA: PCX, BMP, IMG, HEX ,GDI
PPLB: PCX, Binary raster , GDI | |
| | Emulation | PPLA / PPLB | |
| | Software - Label editing | Windows Driver (Win 2000/XP/Vista/Windows 7) BarTender, ArgoBar Pro | |
| | Software - Utility | Printer Utility,Font Utility | |
| | Media Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper | |
| | Media | Max Width: 4.33”(110mm) Min Width:1”(25.4mm) Thickness: 0.0025”~0.01”(0.0635~0.254mm) Max roll capacity(OD): 4.3”(109mm) Core size:1”(25mm) optional, 0.5”(12.7mm) | |
| | Ribbon | Ribbon Width: 1”~4” Ribbon roll – max OD: 1.45”(37mm) Ribbon Length: max 92m Core size – ID: 0.5”(13mm) with notch, Wax, Wax/Resin, Resin (Outside Ribbon) | |
| | Dimensions | W 186mm x H 165mm x L 278mm | |
| | Weight | 2.0kgs | |
| | Power Source | Universal Switching Power Supply Input: 100V~240V, 1.5A, 50~60Hz, Output: 24VDC, 2.4A | |
| | Operation Environment | Operation Temperature: 40°F~100°F (4°C~38°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C) | |
| | Optional Items | Cutter, Stacker, RTC Card, Asian Font Card(Traditional Chinese, Simplified Chinese, Korean and Japanese), ArgoKee | |
| | Agency Listing | CE, FCC, UL, CUL, CCC, RoHS | |
| | Attention | *This data sheet is for informational purposes only. Argox makes no warranties, expressed or implied in this summary. Specifications are subject to change without notice. All trademarks are the property of their respective owners. More specific information, please refer to user’s manual. | |
| | | | |
