Full Color Tube Chip Color and 6.25mm Pixels High Quality Waterproof Outdoor Led Display Board

p5Specifications: Indoor outdoor 1000x500mm p3.91mm p4.81mm p5.95mm p6.25mm New Patent indoor stage used P6mm flexible led curved display screen for concert
2.Vivid color
3.CE, RoHS, FCC 4.High brightness
5.Wide viewing angle, definition
6.Low voltage and power consumption
7.High stability   Features:     Product Description   Indoor outdoor 1000x500mm p3.91mm p4.81mm p5.95mm p6.25mm New Patent indoor stage used P6mm flexible led curved display screen for conert 1.Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.

2.Thin cabinet:the thickness is only 6.5 CM, the space of the screen is small , and the entire screen will be more beautiful.

3.Flat screen:smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively. The effect of the display will be more clear and exquisite.

4. Quick dismounting:adopt fast locking structure connected, firm, quick, beautiful.

5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.     Full Color Tube Chip Color and 6.25mm Pixels High Quality Waterproof Outdoor Led Display Board Technical Parameters:

Indoor Outdoor Aluminum Stage Rental LED Parameters(straight and Curved Two Panel)
Pitch/mm	P3.91/P4.81	P4.81/P5.95/P6.25/P6.94
Module size/mm	250x250	250x250
Density of pixel/(dots/m2)	65746/43264	43264/28224/25600/20736
Pixel composition	1R1G1B	1R1G1B
Led encapsulation	SMD2121/3528	SMD2828/3528/3535
Resolution of module	64x64/52x52	52X52/42x42/40x40/36x72
Optimum viewing distance	≥4/5	≥4/5/6/7
View angle / °	140 H,140 V	140 H,140 V
Average power consumption/W/M2	120	120
Max power consumption/W/M2	250	250
Size of cabinet/mm	1000X500	1000X500
Resolution of cabinet	128X256/104x208	104x208/84x168/80x160/144x72
Weight of cabinet/kg	9.5	10
Driving method	1/16 1/13 scan constant current	1/13 1/7 1/10 1/9 scan constant current
Frame frequency / Hz/S	60	60
Refresh rate Hz/S	≥1200	≥1200
Luminance of white balance	≥1500 nits	≥3000/5000/5500 nits
Operation of Environmental Temperature/°C	below 20 to above 50	below 20 to above 50
IP rating	IP43	IP65
Working vlotage	110-220 VAC/+/- 10%	110-220 VAC/+/- 10%
Grey scale/color	displaying colors≥16.7M(synchronized)	displaying colors≥16.7M(synchronized)
Brightness adjustment	256 levels of each color(manually),100 levels of each color(automatically)	256 levels of each color(manually),100 levels of each color(automatically)

  [LED Cabinets Pictures]         Packaging & Shipping Waterproof P10 single Red color LED module panel with RoHS,CE Approach Package: wooden case or flight case. Shipping: A. By air, From factory to the most closed air port of destination.   B. By world wide express, always use DHL,UPS, TNT, Fedex, EMS, door to door service   C. By ship, the slowest shipping, from factory to the most closed sea port of destination.           Our Services  Quotation services 1. Offer the best solution for customers as required. 2.Offer the best price for with a specification 3.2-5 years warranty time.     Company Information Shenzhen Top Brilliant Electronics Co. , Limited promote the environment protection and energy saving with LED technology,we adopt the LED characterized with energysaving and envronmental friendliness as basic raw material. Now TOPLED offer :Rental LED Screen , Fixed Installation LED ScreenTransparent LED Curtain Screen,Dance Floor/Stair LED Screen,Flexible LED Screen,Front access LED Screen.and Perimeter LED Screen.   TOPLED consider product quality as company life, we take serial reliable tests in each process from the initial production until finished product. The tests cover all important performances, including flatness, power consumption, brightness, color, shock resistance;IP rating and so on, TOPLED adopt the most strict quality control system to guarantee products with perfect quality.     FAQ   1. What is LED?
LED is sanded for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.
2. What are Pixel Pitch, Pixel Density, LED QTY, and Pixel Configuration?
Pixel Pitch is the distance between neighboring pixels.
Pixel Density is the quantity of pixels per square meter.
LED QTY is the quantity of LED lamps per square.
Pixel Configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.
3. What are LED Type, Module size and Module resolution?
LED Type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp, etc.
Module size is the measurement of a module.
Module resolution is the number of pixels per module.
4. What is Drive Method, driving IC and Power supply
Drive Method: always we use static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.
Driving IC is the generic term for several kinds of IC, that are used to control the LED lamps, and as a bridge between the control system and lamps.
Power supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.
5. What is viewing angle?
Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance. It includes horizontal viewing angle and vertical viewing angle.
