2.8inch Digital Door Viewer,Digital Door Peephole Viewer PY-V516

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Specifications 1.PIR Auto-detection function

2.Video format: JPEG, MP4

3.Photo snapping and video recording

2.8inch Digital Door Viewer,Digital Door Peephole Viewer PY-V516

Technical Parameters:

Description		Specification&Feature	Remarks
Machine Part	Indoor unit size	138mm103mm25mm
	Outdoor unit size	18mm*Dia.50mm
	Adapter plate	100mm78mm9.5mm
	Ambient light adaptation	Working environmentIllumination of the outdoor unit20 lux~3500 lux
	Resolution	The resolution of images on the indoor monitor should not be less than 200 (Central level, under800 lux condition)
MIC part	Capacitive ElectretMicrophone	Diameter 6MM Height: 2.7MMSensitivity: 40 + /-3dB
Camera Part	Camera Pixel	Width:640, Height:480	300K Pixel
	Camera Angle	Diagonal:115+/-5 degreesHorizontal:102+/-3 degreesVertical: 85+/-3 degrees
	Digital Zoom	3X digital zoom
Loudspeaker Part	Loudspeaker	Diameter: 20MM Power: 1WImpedance: 8 OHM
Display Screen	Display Type	240(R+G+B)*320 Dots
	LCD Type	2.8 inch TFT LCD
	Viewing Direction	6 O”colock
	Backlight	4 LED white color
Water-proof dust-proof requirements		Indoor Unit: IP30;Outdoor Unit: IP33
Installation Part	Door Thickness suited	Door thickness is: 35mm-55mm,55mm-85mm and 85mm-105mm.Can be customized so that fit for any thickness of the door
Installation Part	Door peephole size	Dia.15mm
Memory	Own memory	256M
Memory	Memory Extension	Maximum support 32G SD card and backward compatible
Power Part	Battery Charger(MODEL:VA8B-050100)	Input: 110 V to 240 V 50/60 Hz, 0.3 AOutput: DC 5.0 V 1.0A	5.0V
	Battery Pack(lithium-ion)(MODEL:DS-L600)	Voltage/capacity: 3.7 V, 1800 mAh
	Clock battery	Dia.20.0 thick:3.2 3.0V CR2032
Infrared mobile monitoring	Distance	Near: <1.5M ; Far: <2.5M
Working Condition	Ambient temperature	-10 °C~+55 °C;
	Relative Humidity	10 %~95 %;
	Atmospheric pressure	86 kPa~106 kPa
Others	Include SD card or not	Optional according to customer’s request
	Include battery	Include 1pc 1800mAh lithium battery
	Language	Kinds of language to set
	Settings function	time and date settings function
	Sleep automatically	Can automatically go to sleep
	File save format	JPEG,MP4
