Top Selling Chinese Good Access Control Panel Supplier

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Top Selling Chinese Good Access Control Panel Supplier Specification

communication	TCP IP
Software support data base	SQL
Communication	TCP/IP, IE Browser
Controlled Readers	2PCS
Can control the door output relay	2pair
English Software supportable database	SQL
Door opening time extending setting	1-600 Seconds(adjustable)
Power Supply	12VDC; 4-7A
Power Consumption of Circuit Board	Less than 100mA
Input Format of Reader	Wiegand 26/34 bit (All card reader with compatible protocol,such as EM, IC etc, Operation Humidity 10-90 % RH ,No Condensation
Operation Humidity	10-90 % RH ,No Condensation
Quantity of users	20,000 Users
Quantity of Event	Buffers(offline) 100,000 Event Buffers
Max distance between controller to the PC	No limits
Max distance for the bus line	Depends on Network
Max distance(Reader to controller)	100 meters, suggest within 80 meters
Max quantity of controller	Unlimited
The card reader, door sensor and button line:	Network lines
Controller relationships	Each works independently and keeps its own database
Alarm input	programmable
Software	English
SDK	Available
PCB board size	160mm * 106mm
Case Size	273mm * 228mm * 65mm

Access management functional schedule:

Compulsive open and close door at long time	√
Open door in remote distance	√
Inter block	×(only work for 2door and 4 door)
Anti pass back and tail	√
Multi-card open door	√
Open long time at specified time	√
Electronic map	√
Urgency locking	√
First card unlocking	√
Unlock based on internal and external validation	√
