55" ips panel tft touch screen lcd monitor
- Min. Order:
- 10 Piece/Pieces
- Min. Order:
- 10 Piece/Pieces
- Transportation:
- Ocean, Air, Express
- Port:
- Shenzhen, Hong Kong
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|---|
| Productivity: | 10000 |
| Supply Ability: | 5000 |
| Payment Type: | T/T,Paypal |
| Incoterm: | FOB,CIF,EXW |
| Transportation: | Ocean,Air,Express |
| Port: | Shenzhen,Hong Kong |
touch monitor, touch screen monitors, touch screen display, touch monitoring, touch monitor price, touch monitors for pc
Industrial LCD touch screen monitors are widely used in various fields such as multimedia, mobile telecommunications, power defense, automation equipment, and manufacturing industries. Industrial LCD touch screen monitors can be used for operating man-machine interfaces, industrial clients, communication and control terminals such as PLC and POS. It can also be used as a media (advertising) player or query terminal in public places such as banks, shopping malls, hotels, railway stations, buses, subway stations, and parks.
In addition to being used in the above fields, industrial LCD touch screen monitors can also be used in high-end communities as home service terminals to realize intercom, message, cost inquiry, product ordering, household appliances management, temperature and humidity control, etc.
ndustrial touch monitor,industrial touch screen monitors,industrial grade touch screen monitor,industrial touch display,industrial display monitors,industrial touch screen displays
Touch Screen Monitors Features:
* Professional aluminum profile narrow frame structure design, stylish and generous appearance;Touch Screen Monitors
*Adopt HD industrial grade A+ LCD screen, designed for touch display; Touch Screen Monitors
*High brightness, high contrast, high definition, enhance the layering of the image; Touch Screen Monitors
*16.7M color, real reproduction of every detail of the image; Touch Screen Monitors
*Using the latest 3D digital filtering and 3D digital noise reduction technology to better eliminate bright color and variegated interference; Touch Screen Monitors
*8ms fast response , remove the picture smear, automatically eliminate the residual image function; Touch Screen Monitors
*178 ° wide viewing angle, to ensure the image display is not deformed, no distortion; Touch Screen Monitors
*Intelligent temperature control, environmentally friendly and quiet; Touch Screen Monitors
*Long life, strong stability, more than 60,000 hours service life, 7*24 hours uninterrupted work throughout the year;
*Full metal casing design, anti-static, anti-magnetic field, anti-interference, no radiation;
*Multi-level menu display function, more convenient to control;
*Adopting VESA wall mounted standard, each machine is equipped with a humanized handle, which is more convenient to install;
*Rich interface to meet the needs of many applications.
Touch Screen Monitors Specification(Support android/windows system)
|
Panel type |
55" FullHD Panel |
|
Physical resolution |
1920（H）× 1080（V） |
|
Pixel pitch |
0.63mm × 0.63mm |
|
Aspect ratio |
16:9 |
|
Response time |
5ms |
|
Brightness |
350 cd/m2 can change LED backlight ,brightness to 1500cd/m2 |
|
Contrast ratio |
1200:1 |
|
Viewing angle |
178°（H）/ 178°（V） |
|
Colors |
16.7M |
|
Video output |
LVDS output |
|
Signal input |
VGA×1 |
|
Digital input |
DVI×1，HDMI×1，1080P（1920×1080）downward compatible |
|
USB input |
USB×1 |
|
RS233 input |
Support remote RS232 control input |
|
Audio output |
10W Speaker× 2 |
|
Intelligent cooling system |
Intelligent temperature control fan, fan self-test function, save energy, reduce noise, reduce overall temperature, improve machine reliability |
|
Built-in touch system |
Metal grid capacitive touch METAL MESH Touch, visible area 1222*689, unlimited resolution |
|
System control mode |
Chinese and English language switching, contrast, brightness, sharpness, color saturation, hue, signal switching, source browsing, color temperature adjustment, re-display rate switching, running status display |
|
Operation mode |
Wire control， infrared remote control，remote control |
|
Bus control |
I2C |
|
Video formats |
PAL、NTSC3.58、NTSC4.43 |
|
Voltage input |
100~240V AC |
|
Power consumption |
≤130W |
|
Dimensions |
1306mm×778mm×56mm（L×W×H） |
|
Active Area Size |
1209mm×680mm（L×W） |
|
Mounting holes |
800mm×400mm（L×W） |
|
Weight(G.W.) |
About 50kg |
|
Installation method |
Self-contained mounting hole, base (optional), pylon (optional), cabinet (support) |
|
Storage temp. |
-20ºC~60ºC |
|
Working temp. |
-10ºC~50ºC |
|
Working Humidity |
10~90% ，relative humidity：≤85% without condensation |
|
Case material |
Metal case, anti-static, anti-magnetic field, strong electric field interference |
|
Quality standards |
International Certification FCC,CE,ROHS |
|
Environmental standards |
All components and packaging accessories meet international environmental standards |
The ports support customization according to customers' requirements
