Product Description
Product Description

10.4 Inch Industrial Grade TFT Panel Monitor uses a modular design. Environmental performance complies with GJB 322A military computer general specifications, and EMC performance complies with GJB 151B military equipment related requirements. It is currently widely used in various vehicle communication systems. Touch Screen Monitor, lcd monitor, led vs lcd monitor, lcd monitor vs led. Multiple I / O port design, the whole machine is reinforced and installed, which effectively improves the anti-vibration performance of the whole machine. The product is fully optimized in terms of vibration reduction, reinforcement installation, heat dissipation and EMC. The casing is made of stainless steel. The environmental performance meets the general specifications of GJB 322A military computer. The EMC performance meets the requirements of GJB 151B military equipment.  industrial monitors, tft color lcd monitor.


Panel Mount Monitor

LCD Monitor 4K

Key Features:


Mitsubishi industrial grade TFT panel.


450nits brightness.


Vandal-proof 10 points projected capacitive touchscreen (PCAP).


USB & RS232 touch interfaces, plug and play.


PCAP is driver free for Win7/Win8 OS.


One-piece silicone gasket sealing, IP65 front panel.


Heat dissipating aluminum structure.


VGA+DVI-D signal inputs, auto detect and auto switch.


100-240V AC power input, low power consumption.


Designed for industrial control system, kiosks.


Product specification


Model No.

HSIM-8419

LCD panel

Size/Aspect ratio

8.4''/4:3

Pixel numbers

1024(H)*768(V)

Brightness

450 cd/m2

Contrast Ratio

700:1

Viewing Angle

160° (H)/140° (V)

Colors

16.7 M

Input terminals

PC signal

VGA, DVI-D

Power jack

100-240V AC power jack

OSD Control

Menu, Auto, Up, Down, Power

Touchscreen interface

USB & RS232

Operating condition

Temperature

-10°C to 50°C (Operating)

-20°C  to 65°C (Storage )

Humidity

10% RH to 90% RH (Operating)

5% RH to 95% RH (Storage)

Touchscreen

10 points projected capacitive, driver free for Win7/Win8 OS

Interface: USB / RS232

Power

Input Voltage

100-240V AC

Operation

30 watt

Stand-by

1 watt

Mount

VESA 75*75mm, panel mount

Accessories

Power cord, USB cable
