FC Single-mode/Multi-mode optical fiber connectors

Specifications FC, SC, ST, LC, DIN, MTRJ, etc.

Zirconia ferrules for FC, SC ,ST, LC and DIN fiber optic connectors

SM and MM

Durable

FC Single-mode/Multi-mode optical fiber connectors   Fiber optic boot

FEATURE :
Low insertion loss and back reflection loss
Free-floating ceramic ferrule
UL-rated plastic housing and boot
Boots in a variety of colors
High precision alignment

AVAILABILITY :
-The connector can be supplied as a pre-assembled one-piece connector or as connector kits.
-Clips are available for SC and LC duplex connectors
Housing kits without ferrule are available.
-PC and APC are available

SPECIFICATIONS:
Insertion Loss: Single mode l≤0.20dB & Multimode ≤0.25dB
Return Loss: UPC ≥50 dB, SPC ≥55 db & APC ≥65 dB
Durability <0.20 dB typical change, 1000 mating
Operating Temperature: -40 to + 80º C
Ferrule Hole Sizes:
Single mode: 125.0+1/-0μm, Concentricity: ≤1.0μm, 125.5+1/-0μm, Concentricity: ≤1.0μm, 126.0+1/-0μm, Concentricity: ≤1.0μm
Multi mode: 125μm, Concentricity: 1≤3μm or 127μm, Concentricity: 1≤3μm or 128μm, Concentricity: 1≤3μm
