Industrial Series LLC210D3-001Optical Liquid Level Sensors

Industrial Series LLC210D3-001Optical Liquid Level Sensors   GENERAL DESCRIPTION: The liquid level sensor provides single point liquid detection via a TTL compatible push pull output. An infra-red LED and phototransistor accurately positioned at the base of the sensing tip ensure good optical coupling between the two when the sensor is in air. When the sensing tip is immersed in liquid, the infra-red light escapes from the cone causing a change in the amount of light present at the phototransistor which makes the output change state.   CLEANING: Proper fluids should be selected based on type of contamination to be removed. SST Sensing recommends freon and alcohol based solvents. DO NOT use chlorinated solvents such as tricholorethane as these are likely to attack the sensor material.   Liquid Media Compatibility: Before use check that the fluid in which you wish to use these devices is compatible either with polysulphone or trogamid.   ELECTRICAL SPECIFICATIONS:               PRODUCT DIMENSIONS:   (All dimensions in mm)             Welcome to your inquiry  !
